Land Rover Discovery L319 (2004-2009) reverse lamp switch Wiring diagrams
This page contains all the electrical diagrams for the component. reverse lamp switch, in which he is found in the car Land Rover Discovery L319 (2004-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram reverse lamp switch (1 of 2)
BATTERY JUNCTION BOX
BLK WIRE
BRN WIRE
BRN/GRN WIRE
CENTRAL JUNCTION BOX
COMPUTER DATA LINES SYSTEM
FUSE 5
FUSE 6
FUSE LINK 16
GENERIC ELECTRONIC MODULE
GRN/BRN WIRE
HOT AT ALL TIMES
IGN
IGNITION SWITCH
LEFT REVERSE LAMP
LEFT STOP LAMP
REVERSE LAMP SWITCH
REVERSE RELAY
RIGHT REVERSE LAMP
RIGHT STOP LAMP
TRAILER CONNECTOR CIRCUIT
TRANSMISSION CONTROL MODULE
YEL WIRE
YEL/BLU WIRE
YEL/WHT WIRE
Go to component -> Backup lamps circuit -> REVERSE LAMP SWITCH
Wiring diagram reverse lamp switch (2 of 2)
BATTERY JUNCTION BOX
BLK WIRE
BRN WIRE
BRN/GRN WIRE
CENTRAL JUNCTION BOX
COMPUTER DATA LINES SYSTEM
FUSE 5
FUSE 69
FUSE LINK 16
GENERIC ELECTRONIC MODULE
GRN/BRN WIRE
GRN/RED WIRE
HOT AT ALL TIMES
HOT IN RUN
IGNITION SWITCH
INTERIOR MIRROR
REVERSE LAMP SWITCH
REVERSE RELAY
RUN WIRE
TRANSMISSION CONTROL MODULE
YEL WIRE
YEL/BLU WIRE
YEL/WHT WIRE
Go to component -> Electrochromic mirror circuit -> REVERSE LAMP SWITCH
