Land Rover Discovery L318 (2002-2004) audio system head unit Wiring diagrams
This page contains all the electrical diagrams for the component. audio system head unit, in which he is found in the car Land Rover Discovery L318 (2002-2004). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram audio system head unit (1 of 2)
ACCESSORY CONNECTOR
AIR TEMPERATURE CONTROL ECU
AUDIO SYSTEM HEAD UNIT
AUTOMATIC GEAR BOX SELECTOR INDICATOR LAMP
BLK WIRE
CENTRAL DOOR LOCKING SWITCH
DIGITAL CLOCK
FRESH RECIRCULATED AIR SWITCH
FUEL FLAP RELEASE SWITCH
FUSE 11
FUSE 33
GLOVE BOX LAMP)
GLOVE BOX SWITCH
GRY/GRN WIRE
HEAD
HEATER CONTROL ILLUMINATION
HILL DESCENT SWITCH
HOT AT ALL TIMES
INSTRUMENT ILLUMINATION DIMMER
LEFT REAR WINDOW SWITCH
LIGHTING SWITCH
OFF
OFF ROAD MODE SWITCH
PASSENGER COMPARTMENT FUSE BOX
REAR AIR CONDITIONING SWITCH
REAR BLOWER SWITCH
RED WIRE
RED/BLK WIRE
RED/BRN WIRE
RED/ORG WIRE
RIGHT REAR WINDOW SWITCH
W/ ATC
W/O ATC
WINDOW LIFT ISOLATION SWITCH
Go to component -> Instrument illumination circuit (1 of 2) -> AUDIO SYSTEM HEAD UNIT
Wiring diagram audio system head unit (2 of 2)
