Land Rover Discovery L318 (2002-2004) 4 oxygen sensor system Wiring diagram
This page shows the only wiring diagram for the component.4 oxygen sensor system, which is found in the car Land Rover Discovery L318 (2002-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 4 oxygen sensor system (1 of 1)
4 OXYGEN SENSOR SYSTEM
ABS MODULATOR
ABS RETURN PUMP
AIR CONDITIONING COMPRESSOR CLUTCH
AIR INJECTION PUMP
BLK WIRE
BLOWER MOTOR SWITCH
BLOWER RELAY
BRN WIRE
CAMSHAFT POSITION SENSOR
DIODE
ENGINE CONTROL MODULE
FUEL BURNING HEATER PUMP
FUEL TANK UNIT
HORNS
IDLE SOLENOID SUPPRESSOR
LEFT FRONT FOG LAMP
LEFT HEADLAMP
LEFT REAR SELF LEVELING SUSPENSION VALVE
OXYGEN SENSOR SHIELDS
POWER WASH PUMP
REAR SCREEN WASHER PUMP
RESISTOR PACK
RIGHT FRONT FOG LAMP
RIGHT FRONT SIDE REPEATER LAMP
RIGHT HEADLAMP
RIGHT REAR SELF LEVELING SUSPENSION VALVE
SELF LEVELING SUSPENSION EXHAUST VALVE
SELF- LEVELING ABS ECU
SELF- LEVELING SUSPENSION COMPRESSOR
SHIELD
WATER FILTER SENSOR
WINDSCREEN WASHER PUMP
Go to component -> Ground distribution circuit (1 of 5) -> 4 OXYGEN SENSOR SYSTEM
