Land Rover Discovery IV facelift (2013-2016) portable devices user interface Wiring diagram
This page shows the only wiring diagram for the component.portable devices user interface, which is found in the car Land Rover Discovery IV facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram portable devices user interface (1 of 1)
ANALOG CLOCK
BLK WIRE
BLK/PNK WIRE
BRAID
CAPACITOR
CENTER INSTRUMENT PANEL SWITCH PACK
CLOCK- SPRING
DIAGNOSTIC SOCKET CONNECTOR
DIGITAL RADIO CONTROL MODULE
DRIVER AIR BAG MODULE
DRIVER LUMBAR PUMP
DRIVER SEAT SWITCH PACK
DRIVER SOLENOID LUMBAR PUMP
ELECTRIC PARK BRAKE CONTROL MODULE
GATEWAY MODULE
GLOVE BOX ILLUMINATION LAMP
HEADER)
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
IGNITION COIL 5
IGNITION COIL 6
IMMOBILIZER ANTENNA UNIT
INSTRUMENT CLUSTER
INTEGRATED CONTROL PANEL
LEFT FRONT FOOTWELL LAMP
LEFT HEADLAMP
LEFT STEERING WHEEL SWITCHPACK
LIGHTING CONTROL SWITCH
LIGHTING STEERING COLUMN SWITCH
MEMORY CONTROL MODULE
MULTI-FUNCTION DISPLAY UNIT
NCA WIRE
PORTABLE DEVICES USER INTERFACE
PROXIMITY SENSOR GENERAL MODULE
RIGHT FRONT FOOTWELL LAMP
RIGHT HEADLAMP
RIGHT STEERING WHEEL SWITCHPACK
RIGHT TAIL LAMP ASSEMBLY
SATELLITE RADIO CONTROL MODULE
STEERING ANGLE SENSOR
STEERING COLUMN ASSEMBLY
STEERING WHEEL HEATER CONTROL MODULE
TELEPHONE INTERFACE MODULE
TRAILER PICK-UP (4 PIN)
TRAILER PICK-UP (7 PIN)
W/ BOLSTER
W/ MEMORY
W/O BOLSTER
W/O MEMORY
WHT WIRE
WIPER STEERING COLUMN SWITCH
Go to component -> Ground distribution circuit (3 of 3) -> PORTABLE DEVICES USER INTERFACE
