Land Rover Discovery IV facelift (2013-2016) left front heated seat module Wiring diagram
This page shows the only wiring diagram for the component.left front heated seat module, which is found in the car Land Rover Discovery IV facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front heated seat module (1 of 1)
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
CENTER INSTRUMENT PANEL SWITCHPACK
CENTRAL JUNCTION BOX
CLIMATE CONTROL MODULE
COMPUTER DATA LINES SYSTEM
DRIVER ELEMENT BACKREST HEATER
DRIVER ELEMENT CUSHION HEATER
ENGINE JUNCTION BOX
FRONT HEATED SEAT RELAY
FUSE 15
FUSE 24
FUSE 62
GRN WIRE
GRN/PPL WIRE
GRY WIRE
HOT AT ALL TIMES
IGN
LEFT FRONT HEATED SEAT MODULE
LEFT SEAT HEATER SW
LT GRN WIRE
MS CAN-H
MS CAN-L
MS MS CAN CAN
PASSENGER ELEMENT BACKREST HEATER
PASSENGER ELEMENT CUSHION HEATER
PPL
QUIESCENT CURRENT CONTROL MODULE
RED WIRE
RED/YEL WIRE
RIGHT FRONT HEATED SEAT MODULE
RIGHT SEAT HEATER SW
THERMISTOR
WHT WIRE
YEL WIRE
YEL/BLU WIRE
YEL/WHT WIRE
Go to component -> Front seat heater circuit -> LEFT FRONT HEATED SEAT MODULE
