Land Rover Discovery IV facelift (2013-2016) diagnostic socket Wiring diagram
This page shows the only wiring diagram for the component.diagnostic socket, which is found in the car Land Rover Discovery IV facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram diagnostic socket (1 of 1)
AIR SUSPENSION MODULE
ANALOG CLOCK
BLK WIRE
BLU WIRE
BRN WIRE
BRN/RED WIRE
CENTER CONSOLE SWITCHPACK
CENTER INSTRUMENT PANEL SWITCHPACK
CENTRAL JUNCTION BOX
CLOCK- SPRING
DIAGNOSTIC SOCKET
DRIVER SEAT SWITCHPACK
ELECTRIC PARK BRAKE CONTROL MODULE
ENGINE CONTROL MODULE
FROM FUSE 5 (DIAGRAM 3 OF 5)
FROM FUSE 64 (DIAGRAM 2 OF 5)
FRONT WASH PUMP RELAY
FUSE 10
FUSE 19
FUSE 20
FUSE 21
FUSE 22
FUSE 37
FUSE 38
FUSE 39
FUSE 40
FUSE 43
FUSE 44
FUSE 47
FUSE 51
FUSE 56
FUSE 61
FUSE 62
FUSE 66
FUSE 9
GRN WIRE
GRN/BLK WIRE
GRN/PNK WIRE
GRN/PPL WIRE
HEADLAMP WASHER PUMP RELAY
HEATED STEERING WHEEL MODULE
IMMOBILIZER ANTENNA UNIT
INSTRUMENT CLUSTER
KEYLESS VEHICLE MODULE
LEFT REAR DOOR MODULE
LEFT STEERING WHEEL SWITCHPACK
LIGHTING CONTROL SWITCH
LT GRN WIRE
MAGNETIC VALVE
MEMORY CONTROL MODULE
OCCUPANT CLASSIFICATION SENSOR CONTROL MODULE
ORG/ WIRE
ORG/GRN WIRE
PASSENGER SEAT SWITCHPACK
PNK WIRE
REAR DIFFERENTIAL CONTROL MODULE
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
RESTRAINTS CONTROL MODULE
RIGHT REAR DOOR MODULE
ROOF OPENING PANEL CONTROL MODULE
TCM, CONTROL VALVE BODY
TRANSFER CASE CONTROL MODULE
WHT WIRE
WINDOW LIFT SWITCHPACK
YEL WIRE
Go to component -> Power distribution circuit (4 of 5) -> DIAGNOSTIC SOCKET
