Car Wiring Diagrams for Radio circuit, low line for Land Rover Discovery IV (2009-2013)

AM/FM DIVERSITY ANTENNA AMPLIFIER ANTENNA PWR AUDIO HEAD UNIT AUX GND AUX L + AUX R + AV INPUT PANEL BLK WIRE BLU WIRE CAN L CENTRAL JUNCTION BOX CLOCK- SPRING COAX COMPUTER DATA LINES SYSTEM FUSE 51 FUSE 64 GND RTN GRN WIRE GRN/BLK WIRE GRN/WHT WIRE GRY/BLK WIRE GRY/RED WIRE HOT AT ALL TIMES MENU DOWN SWITCH MENU LEFT SWITCH MENU RIGHT SWITCH MENU UP SWITCH MS CAN-H MS CAN-L MULTI-FUNCTION DISPLAY UNIT NCA WIRE PHONE OFF SWITCH PHONE ON SWITCH PNK AUDIO (AIP) WIRE PNK WIRE POWER GND PPL PPL COAX RED WIRE REMOTE CTRL- RIGHT FRONT DOOR MID RANGE SPEAKER RIGHT FRONT HIGH RANGE SPEAKER RIGHT REAR HIGH RANGE SPEAKER RIGHT REAR MID-RANGE SPEAKER RIGHT STEERING WHEEL MODULE SCRN SPK-FL - SPK-FR + SPK-RL - SPK-RR - VBATT VOICE COMMAND SWITCH W/ PHONE W/O PHONE WHT WIRE YEL/BLU WIRE YEL/WHT WIRE

BLK WIRE BLU WIRE COMPUTER DATA LINES SYSTEM DRIVER AIR BAG MODULE FRONT INTERIOR LAMP GRN WIRE GRN/WHT WIRE LEFT FRONT DOOR MID RANGE SPEAKER LEFT FRONT HIGH RANGE SPEAKER LEFT REAR HIGH RANGE SPEAKER LEFT REAR MID-RANGE SPEAKER LEFT STEERING WHEEL MODULE LIN IPC LINE IN L LINE IN R LINE OUT L LINE OUT R MIC - MIC IN - MICROPHONE MODE SWITCH MS CAN-H MS CAN-L NCA WIRE PNK WIRE RED WIRE REF IN GND REF OUT GND SEEK SWITCH TELEPHONE MODULE V BATT VOLUME SWITCH WHT WIRE YEL/BLU WIRE YEL/WHT WIRE
