Car Wiring Diagrams for Electronic suspension circuit for Land Rover Discovery IV (2009-2013)

AIR SUSPENSION MODULE AIR SUSPENSION RELAY BATTERY VOLT BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/ORG WIRE BLK/PPL WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BRN WIRE BRN/RED WIRE COMP REL NEG COMP REL POS COMP TEMP GND COMP TEMP SIG COMP V ENGINE JUNCTION BOX EXH V NEG EXH V POS F XV NEG F XV POS FL CV NEG FL CV POS FL HEIGHT GND FL HEIGHT SIG FR CV NEG FR CV POS FR HEIGHT GND FR HEIGHT SIG FRONT CONTROL VALVE (BEHIND RIGHT SIDE OF FRONT BUMPER) FRONT CROSS LINK VALVE FUSE 26 FUSE 3 FUSIBLE LINK 10 GRN WIRE GROUND GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/GRN WIRE GRY/ORG WIRE GRY/RED WIRE GRY/YEL WIRE HOT AT ALL TIMES LEFT FRONT CORNER VALVE LEFT FRONT HEIGHT SENSOR ORG/ WIRE ORG/GRY WIRE PNK WIRE PPL PPL/BLU WIRE PRESSURE GND PRESSURE SENSOR PRESSURE SIG RED WIRE RES V NEG RES V POS RESERVOIR CONTROL VALVE (UNDER LEFT SIDE OF VEHICLE) RESERVOIR VALVE RIGHT FRONT CORNER VALVE RIGHT FRONT HEIGHT SENSOR WHT WIRE YEL WIRE YEL/BLK WIRE YEL/PNK WIRE

ACCESS HT LED AIR SUS CTRL AIR SUSPENSION COMPRESSOR MOTOR AIR SUSPENSION MODULE BLK WIRE BLK/BLU WIRE BLK/BRN WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/ORG WIRE BLK/PNK WIRE BLK/PPL WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BODY CONTROL MODULE (BCM) BRN WIRE BRN/RED WIRE CENTER CONSOLE SWITCH PACK CENTRAL JUNCTION BOX COMPUTER DATA LINES SYSTEM CRAWL LED EXHAUST VALVE FUSE 10 GRN WIRE GRY WIRE GRY/BLU WIRE GRY/RED WIRE GRY/YEL WIRE HIGH (LED) HOT W/ IGNITION RELAY ENERGIZED HS CAN-H HS CAN-L IGN LED NEG LEFT REAR CORNER VALVE LEFT REAR HEIGHT SENSOR LOWER SW LOWER SWITCH LOWERING LED LT GRN WIRE LT GRN/WHT WIRE MOT TEMP GND MOT TEMP SIG ORG/ WIRE ORG/BLK WIRE ORG/RED WIRE ORG/YEL WIRE PNK WIRE PPL R XV NEG R XV POS RAISE SW RAISE SWITCH RAISING LED REAR CONTROL VALVE (UNDER LEFT REAR WHEEL ARCH) REAR CROSS LINK VALVE RED WIRE RIGHT REAR CORNER VALVE RIGHT REAR HEIGHT SENSOR RL CV NEG RL CV POS RL HEIGHT GND RL HEIGHT SIG RR CV NEG RR CV POS RR HEIGHT GND RR HEIGHT SIG STD HT LED TEMPERATURE COMPRESSOR SENSOR TEMPERATURE MOTOR SENSOR WHT WIRE WHT/PNK WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE
