Land Rover Discovery IV (2009-2013) Anti-lock brakes circuit

38 39 GND ABS MODULE AIR CONDITIONING SYSTEM BLK WIRE BLK/GRN WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BODY CONTROL MODULE (BCM) BRAKE PEDAL SWITCH BRK SW 1 BRK SW 2 BRN/GRN WIRE CAN L CENTER CONSOLE SWITCH PACK CENTER INSTRUMENT PANEL SWITCH PACK CENTRAL JUNCTION BOX COMPUTER DATA LINES SYSTEM DPHL DPHR DPVL DPVR DSC SWITCH DSHL DSHR DSVL DSVR ENGINE CONTROL MODULE (ECM) ENGINE JUNCTION BOX FUSE 14 FUSE 21 FUSE 23 FUSE 5 FUSE LINK 9 GRN WIRE GRN/BLK WIRE GRN/PPL WIRE GRN/WHT WIRE HID HILL DESCENT SWITCH HOT AT ALL TIMES HOT W/ IGNITION RELAY ENERGIZED HS CAN-H HS CAN-L IGN LEFT FRONT WHEEL SPEED SENSOR LEFT REAR WHEEL SPEED SENSOR LT GRN WIRE NCA WIRE ORG/GRN WIRE PATA PPL/GRN WIRE PPL/YEL WIRE RED WIRE RIGHT FRONT WHEEL SPEED SENSOR RIGHT REAR WHEEL SPEED SENSOR STEERING ANGLE SENSOR TERRAIN OPTIMISATION SWITCH UBMR UBVR WHT WIRE WHT/GRN WIRE WHT/YEL WIRE YAW RATE SENSOR YEL WIRE YEL/BLK WIRE YEL/BRN WIRE
