Land Rover Discovery IV (2009-2013) steering column motor switch pack Wiring diagrams
This page contains all the electrical diagrams for the component. steering column motor switch pack, in which he is found in the car Land Rover Discovery IV (2009-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram steering column motor switch pack (1 of 2)
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BLU/BLK WIRE
BODY CONTROL MODULE (BCM)
BRN/GRY WIRE
BRN/RED WIRE
BRN/WHT WIRE
CENTRAL JUNCTION BOX
COMPUTER DATA LINES SYSTEM
ENGINE JUNCTION BOX
FUSE LINK 18
GRN WIRE
HOT AT ALL TIMES
ISOLATOR SWITCH
MS CAN-H
MS CAN-L
RED WIRE
STEERING COLUMN ASSEMBLY
STEERING COLUMN MOTOR SWITCH PACK
TELESCOPE SENSOR
TELESCOPE SOLENOID
TELESCOPE SWITCH
TILT SENSOR
TILT SOLENOID
TILT SWITCH
YEL/BLU WIRE
YEL/WHT WIRE
Go to component -> Electronic power steering circuit -> STEERING COLUMN MOTOR SWITCH PACK
Wiring diagram steering column motor switch pack (2 of 2)
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BLU/BLK WIRE
BODY CONTROL MODULE (BCM)
BRN/GRY WIRE
BRN/RED WIRE
BRN/WHT WIRE
CENTRAL JUNCTION BOX
COMPUTER DATA LINES SYSTEM
DRIVER SEAT SWITCH PACK
ENGINE JUNCTION BOX
FET
FUSE LINK 18
GRN WIRE
GRY WIRE
GRY/PPL WIRE
HOT AT ALL TIMES
ISOLATOR SWITCH
LED
MEMORY
MEMORY 1
MEMORY 2
MEMORY CONTROL MODULE (UNDER DRIVER'S SEAT)
MEMORY SET
MS CAN-H
MS CAN-L
RED WIRE
STATUS
STEERING COLUMN ASSEMBLY
STEERING COLUMN MOTOR SWITCH PACK
TELESCOPE SENSOR
TELESCOPE SOLENOID
TELESCOPE SWITCH
TILT SENSOR
TILT SOLENOID
TILT SWITCH
YEL WIRE
YEL/BLU WIRE
YEL/WHT WIRE
Go to component -> Steering column memory circuit -> STEERING COLUMN MOTOR SWITCH PACK
