Land Rover Discovery IV (2009-2013) reverse lamp switch Wiring diagram
This page shows the only wiring diagram for the component.reverse lamp switch, which is found in the car Land Rover Discovery IV (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram reverse lamp switch (1 of 1)
BLK WIRE
BLK/GRN WIRE
BODY CONTROL MODULE
BRN/GRN WIRE
CENTRAL JUNCTION BOX
COMPUTER DATA LINES SYSTEM
ELECTROCHROMIC MIRROR
ENGINE JUNCTION BOX
FUSE 11
FUSE 12
FUSE LINK 16
GRN/BRN WIRE
HOT AT ALL TIMES
HS CAN-H
HS CAN-L
LEFT REVERSE LAMP
LEFT TAIL LAMP UNIT
MS MS CAN CAN
REV
REVERSE LAMP SWITCH
REVERSE RELAY
RIGHT REVERSE LAMP
RIGHT TAIL LAMP UNIT
TCM, CONTROL VALVE BODY
TRAILER PICK-UP (7 PIN)
YEL/BLK WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/WHT WIRE
Go to component -> Backup lamps circuit -> REVERSE LAMP SWITCH
