Land Rover Discovery IV (2009-2013) org/ Wiring diagrams

This page contains all the electrical diagrams for the component. org/, in which he is found in the car Land Rover Discovery IV (2009-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram org/ (11 of 37)

Wiring diagram org/ for Land Rover Discovery IV (2009-2013) (11 of 37)
Get lifetime access to Land Rover Discovery IV (2009-2013)

AIR SUSPENSION MODULE AIR SUSPENSION RELAY BATTERY VOLT BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/ORG WIRE BLK/PPL WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BRN WIRE BRN/RED WIRE COMP REL NEG COMP REL POS COMP TEMP GND COMP TEMP SIG COMP V ENGINE JUNCTION BOX EXH V NEG EXH V POS F XV NEG F XV POS FL CV NEG FL CV POS FL HEIGHT GND FL HEIGHT SIG FR CV NEG FR CV POS FR HEIGHT GND FR HEIGHT SIG FRONT CONTROL VALVE (BEHIND RIGHT SIDE OF FRONT BUMPER) FRONT CROSS LINK VALVE FUSE 26 FUSE 3 FUSIBLE LINK 10 GRN WIRE GROUND GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/GRN WIRE GRY/ORG WIRE GRY/RED WIRE GRY/YEL WIRE HOT AT ALL TIMES LEFT FRONT CORNER VALVE LEFT FRONT HEIGHT SENSOR ORG/ WIRE ORG/GRY WIRE PNK WIRE PPL PPL/BLU WIRE PRESSURE GND PRESSURE SENSOR PRESSURE SIG RED WIRE RES V NEG RES V POS RESERVOIR CONTROL VALVE (UNDER LEFT SIDE OF VEHICLE) RESERVOIR VALVE RIGHT FRONT CORNER VALVE RIGHT FRONT HEIGHT SENSOR WHT WIRE YEL WIRE YEL/BLK WIRE YEL/PNK WIRE

Go to component -> Electronic suspension circuit (1 of 2) -> ORG/ WIRE

Wiring diagram org/ (12 of 37)

Wiring diagram org/ for Land Rover Discovery IV (2009-2013) (12 of 37)
Get lifetime access to Land Rover Discovery IV (2009-2013)

ACCESS HT LED AIR SUS CTRL AIR SUSPENSION COMPRESSOR MOTOR AIR SUSPENSION MODULE BLK WIRE BLK/BLU WIRE BLK/BRN WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/ORG WIRE BLK/PNK WIRE BLK/PPL WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BODY CONTROL MODULE (BCM) BRN WIRE BRN/RED WIRE CENTER CONSOLE SWITCH PACK CENTRAL JUNCTION BOX COMPUTER DATA LINES SYSTEM CRAWL LED EXHAUST VALVE FUSE 10 GRN WIRE GRY WIRE GRY/BLU WIRE GRY/RED WIRE GRY/YEL WIRE HIGH (LED) HOT W/ IGNITION RELAY ENERGIZED HS CAN-H HS CAN-L IGN LED NEG LEFT REAR CORNER VALVE LEFT REAR HEIGHT SENSOR LOWER SW LOWER SWITCH LOWERING LED LT GRN WIRE LT GRN/WHT WIRE MOT TEMP GND MOT TEMP SIG ORG/ WIRE ORG/BLK WIRE ORG/RED WIRE ORG/YEL WIRE PNK WIRE PPL R XV NEG R XV POS RAISE SW RAISE SWITCH RAISING LED REAR CONTROL VALVE (UNDER LEFT REAR WHEEL ARCH) REAR CROSS LINK VALVE RED WIRE RIGHT REAR CORNER VALVE RIGHT REAR HEIGHT SENSOR RL CV NEG RL CV POS RL HEIGHT GND RL HEIGHT SIG RR CV NEG RR CV POS RR HEIGHT GND RR HEIGHT SIG STD HT LED TEMPERATURE COMPRESSOR SENSOR TEMPERATURE MOTOR SENSOR WHT WIRE WHT/PNK WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE

Go to component -> Electronic suspension circuit (2 of 2) -> ORG/ WIRE

Wiring diagram org/ (13 of 37)

Wiring diagram org/ for Land Rover Discovery IV (2009-2013) (13 of 37)
Get lifetime access to Land Rover Discovery IV (2009-2013)

BACKUP LAMP CIRCUIT BLK WIRE BLK/GRN WIRE BLU WIRE BLU/RED WIRE BODY CONTROL MODULE (BCM) BRAKE PEDAL SWITCH BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/WHT WIRE CENTRAL JUNCTION BOX COMPUTER DATA LINES SYSTEM DIRECTION INDICATOR SWITCH DRIVER DOOR MODULE ELECTRIC BRAKE TRAILER MODULE ENGINE CONTROL MODULE (ECM) ENGINE JUNCTION BOX ENGINE RUN FET FUSE 14 FUSE 24 FUSE 25 FUSE 27 FUSE 54 FUSE LINK 15 FUSE LINK 16 FUSE LINK 6 GRN WIRE GRN/PPL WIRE GRN/RED WIRE GRN/WHT WIRE HOT AT ALL TIMES HOT W/ ACCESSORY SOCKET RELAY ENERGIZED HS CAN-H HS CAN-L IGN INSTRUMENT CLUSTER LEFT FRONT SIDE REPEATER LAMP LEFT TURN SIGNAL IND LH IND/STOP MS MS RH CAN CAN IND IND ORG/ WIRE PASSENGER DOOR MODULE PNK/WHT WIRE POSITION LAMP RELAY PPL/GRN WIRE PPL/YEL WIRE REAR WIPER TRAILER RELAY RED WIRE RED/BLK WIRE RED/ORG WIRE RED/WHT WIRE REV RH IND/STOP RIGHT FRONT SIDE REPEATER LAMP RIGHT TURN SIGNAL IND STEERING COLUMN LIGHTING SWITCH TAIL TO LEFT REAR IND FET (DIAGRAM 2 OF 2) TO RIGHT IND FET (DIAGRAM 2 OF 2) TRAILER PICK-UP (4 PIN) TRAILER PICK-UP (7 PIN) TRAILER SOCKET RELAY WHT WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/WHT WIRE

Go to component -> Exterior lamps circuit (1 of 2) -> ORG/ WIRE

Wiring diagram org/ (14 of 37)

Wiring diagram org/ for Land Rover Discovery IV (2009-2013) (14 of 37)
Get lifetime access to Land Rover Discovery IV (2009-2013)

AUDIO HEAD UNIT DAB/SDARS TUNER MODULE (BEHIND RIGHT REAR TRIM PANEL) MOST IN MOST OUT ORG/ WIRE PORTABLE AUDIO INTERFACE MODULE (UNDER LEFT FRONT SEAT) POWER AMPLIFIER (UNDER RIGHT FRONT SEAT) REAR SEAT ENTERTAINMENT MODULE REAR SEAT ENTERTAINMENT MODULE (RIGHT REAR TRIM PANEL) TELEPHONE MODULE (BEHIND RIGHT REAR TRIM PANEL) TOUCH SCREEN DISPLAY W/ DAB/ SDARS TUNER W/ RSE W/ RSE, DAB/ SDARS TUNER W/ RSE, TELEPHONE W/ RSE, TELEPHONE, DAB/ SDARS TUNER W/ TELEPHONE W/ TELEPHONE, DAB/ SDARS

Go to component -> Fibre optic network circuit, w/ rse, dab/sdars tuner & telephone -> ORG/ WIRE

Wiring diagram org/ (15 of 37)

Wiring diagram org/ for Land Rover Discovery IV (2009-2013) (15 of 37)
Get lifetime access to Land Rover Discovery IV (2009-2013)

DAB/SDARS TUNER MODULE (BEHIND RIGHT REAR TRIM PANEL) IBOC RADIO MODULE (RIGHT SIDE OF LUGGAGE COMPT) MOST IN MOST OUT ORG/ WIRE PORTABLE AUDIO INTERFACE MODULE (UNDER LEFT FRONT SEAT) POWER AMPLIFIER (UNDER RIGHT FRONT SEAT) REAR SEAT ENTERTAINMENT MODULE (RIGHT REAR TRIM PANEL) TELEPHONE MODULE (BEHIND RIGHT REAR TRIM PANEL)

Go to component -> Fibre optic network circuit, w/ rse, dab/sdars tuner, telephone & iboc radio (2 of 2) -> ORG/ WIRE

Wiring diagram org/ (16 of 37)

Wiring diagram org/ for Land Rover Discovery IV (2009-2013) (16 of 37)
Get lifetime access to Land Rover Discovery IV (2009-2013)

AUDIO HEAD UNIT DAB/SDARS TUNER MODULE (BEHIND RIGHT REAR TRIM PANEL) MOST IN MOST OUT ORG/ WIRE PORTABLE AUDIO INTERFACE MODULE (UNDER LEFT FRONT SEAT) POWER AMPLIFIER (UNDER RIGHT FRONT SEAT) REAR SEAT ENTERTAINMENT MODULE (RIGHT REAR TRIM PANEL) TELEPHONE MODULE TELEPHONE MODULE (BEHIND RIGHT REAR TRIM PANEL) TELEVISION RECEIVER TOUCH SCREEN DISPLAY W/ DAB/SDARS TUNER, RSE, TELEVISION RECEIVER W/ DAB/SDARS TUNER, TELEVISION RECEIVER W/ RSE, TELEPHONE, DAB/SDARS TUNER, TELEVISION RECEIVER W/ RSE, TELEPHONE, TELEVISION, RECEIVER W/ RSE, TELEVISION RECEIVER W/ TELEPHONE, DAB/SDARS TUNER, TELEVISION RECEIVER W/ TELEPHONE, TELEVISION RECEIVER W/ TELEVISION RECEIVER

Go to component -> Fibre optic network circuit, w/ rse, dab/sdars tuner, telephone & television receiver (1 of 2) -> ORG/ WIRE

Wiring diagram org/ (17 of 37)

Wiring diagram org/ for Land Rover Discovery IV (2009-2013) (17 of 37)
Get lifetime access to Land Rover Discovery IV (2009-2013)

ABS MODULE AFS CONTROL MODULE AIR SUSPENSION MODULE AIR SUSPENSION RELAY AUXILIARY DRIVING LAMP RELAY BATTERY BLK WIRE BLOWER RELAY BLU WIRE BRN WIRE BRN/GRN WIRE ELECTRIC BRAKE TRAILER MODULE ELECTROCHROMIC MIRROR ENGINE CONTROL MODULE ENGINE JUNCTION BOX EXTENDED IGNITION RELAY FROM FUSE LINK 13 (DIAGRAM 1 OF 4) FRONT HEATED SCREEN RELAY FRONT HEATED SEAT RELAY FUEL PUMP RELAY FUSE 16 FUSE 19 FUSE 20 FUSE 21 FUSE 22 FUSE 23 FUSE 24 FUSE 25 FUSE 26 FUSE 27 FUSE 29 FUSE 8 FUSE LINK 10 FUSE LINK 11 FUSE LINK 12 FUSE LINK 13 FUSE LINK 14 FUSE LINK 19 FUSE LINK 2 FUSE LINK 20 FUSE LINK 3 FUSE LINK 6 FUSE LINK 8 FUSE LINK 9 GENERATOR GRN WIRE GRN/YEL WIRE GRY WIRE HEATED WASHER JETS/DOOR MIRRORS RELAY HORN RELAY LEFT HEADLAMP LT GRN WIRE MEGA FUSE ORG/ WIRE PARKING AID MODULE PARKING BRAKE MODULE PNK PNK WIRE PNK WIRE PNK/WHT WIRE POWER AMPLIFIER PPL PPL/ORG WIRE PPL/YEL WIRE REAR BLOWER RELAY REAR DIFFERENTIAL CONTROL MODULE REAR HEATED SEAT RELAY REAR WIPER TRAILER RELAY RED WIRE RH HEATER SEAT RELAY RIGHT HEADLAMP STARTER MOTOR STARTER RELAY TO CENTRAL JUNCTION BOX (DIAGRAM 2 OF 4) TO CENTRAL JUNCTION BOX (DIAGRAM 3 OF 4) TO FUSE 16 (DIAGRAM 1 OF 4) TO FUSE LINK 16 (DIAGRAM 2 OF 4) TRANSFER BOX CONTROL MODULE TRANSIT RELAY WHT WIRE WIPER FAST- SLOW RELAY WIPER ON/ OFF RELAY YEL WIRE

Go to component -> Power distribution circuit (1 of 4) -> ORG/ WIRE

Wiring diagram org/ (18 of 37)

Wiring diagram org/ for Land Rover Discovery IV (2009-2013) (18 of 37)
Get lifetime access to Land Rover Discovery IV (2009-2013)

ABS MODULE AMBIENT LIGHT/ RAIN SENSOR AUXILIARY LIGHTING SWITCH BATTERY BACKED SOUNDER BATTERY SAVER RELAY BLK WIRE BLU WIRE BODY CONTROL MODULE (BCM) BRAKE PEDAL SWITCH BRN WIRE BRN/BLU WIRE BRN/RED WIRE CENTRAL JUNCTION BOX COOL BOX DRIVER DOOR MODULE ENGINE CONTROL MODULE RELAY ENGINE JUNCTION BOX FROM ENGINE JUNCTION BOX (DIAGRAM 1 OF 4) FROM FUSE LINK 18 (DIAGRAM 2 OF 4) FROM IGNITION RELAY (DIAGRAM 3 OF 4) FRONT INTERIOR LAMP FUEL FLAP LOCK RELAY FUEL FLAP UNLOCK RELAY FUSE 1 FUSE 14 FUSE 16 FUSE 17 FUSE 18 FUSE 23 FUSE 29 FUSE 30 FUSE 31 FUSE 32 FUSE 33 FUSE 34 FUSE 36 FUSE 4 FUSE 49 FUSE 5 FUSE 50 FUSE 57 FUSE LINK 15 FUSE LINK 17 FUSE LINK 7 GEARSHIFT MECHANISM GLOVE COMPARTMENT LAMP GRN WIRE IGNITION RELAY IGNITION RESTRAINTS RELAY INTERIOR LAMP FET KEYLESS VEHICLE MODULE LEFT HEADLAMP LEFT MAP LAMP LEFT POWER WASH RELAY LEFT VANITY MIRROR LICENSE PLATE LAMP, TAIL DOOR SWITCH LOGIC GND LT GRN WIRE LT GRN/WHT WIRE ORG/ WIRE PASSENGER DOOR MODULE POSITION LAMP RELAY POWER WASH RELAY PPL RADIO FREQUENCY (RF) RECEIVER REAR INTERIOR LAMP REAR WINDOW HEATED RELAY RED WIRE RIGHT HEADLAMP RIGHT MAP LAMP RIGHT VANITY MIRROR START/ STOP SWITCH STEERING ANGLE SENSOR STOP TO FUSE 36 (DIAGRAM 3 OF 4) TO FUSE 9 (DIAGRAM 4 OF 4) VOLUMETRIC SENSOR W/ KEYLESS ENTRY W/O KEYLESS ENTRY WHT WIRE YAW RATE SENSOR YEL WIRE

Go to component -> Power distribution circuit (3 of 4) -> ORG/ WIRE

Wiring diagram org/ (19 of 37)

Wiring diagram org/ for Land Rover Discovery IV (2009-2013) (19 of 37)
Get lifetime access to Land Rover Discovery IV (2009-2013)

AIR SUSPENSION MODULE ANALOG CLOCK AUDIO HEAD UNIT BLK WIRE BLU WIRE BRN WIRE BRN/RED WIRE CAMERAS MODULE CENTER INSTRUMENT PANEL SWITCH PACK CENTER PACK CONSOLE SWITCH CENTRAL JUNCTION BOX CLIMATE CONTROL MODULE CLOCK- SPRING DIAGNOSTIC SOCKET DRIVER SEAT PACK SWITCH DRIVER SEAT SWITCH PACK ENGINE CONTROL MODULE FROM FUSE 5 (DIAGRAM 3 OF 4) FROM FUSE 64 (DIAGRAM 2 OF 4) FRONT WASH PUMP RELAY FUSE 10 FUSE 19 FUSE 20 FUSE 21 FUSE 22 FUSE 37 FUSE 38 FUSE 39 FUSE 40 FUSE 43 FUSE 44 FUSE 46 FUSE 47 FUSE 51 FUSE 6 FUSE 61 FUSE 62 FUSE 65 FUSE 66 FUSE 9 GEARSHIFT MECHANISM GRN WIRE GRN/BLK WIRE GRN/PNK WIRE GRN/PPL WIRE HEATED STEERING WHEEL MODULE IMMOBILIZER ANTENNA MODULE INSTRUMENT CLUSTER KEYLESS VEHICLE MODULE LEFT REAR DOOR MODULE LEFT STEERING WHEEL MODULE LIGHTING CONTROL SWITCH LOWER INTEGRATED CONTROL PANEL LT GRN WIRE MAGNETIC VALVE MEMORY CONTROL MODULE ORG/ WIRE PARKING BRAKE MODULE PASSENGER SEAT SWITCH PACK PNK WIRE REAR DIFFERENTIAL CONTROL MODULE REAR WASH PUMP RELAY RED WIRE RED/YEL WIRE RIGHT REAR DOOR MODULE ROOF OPENING PANEL CONTROL MODULE TCM, CONTROL VALVE BODY TELEPHONE MODULE TRANSFER BOX CONTROL MODULE WHT WIRE WINDOW LIFT SWITCH PACK YEL WIRE

Go to component -> Power distribution circuit (4 of 4) -> ORG/ WIRE

Wiring diagram org/ (20 of 37)

Wiring diagram org/ for Land Rover Discovery IV (2009-2013) (20 of 37)
Get lifetime access to Land Rover Discovery IV (2009-2013)

-VE AUDIO HEAD UNIT BLK WIRE BLU/BRN WIRE BLU/ORG WIRE BODY CONTROL MODULE (BCM) BRN WIRE BRN/GRN WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE CENTRAL JUNCTION BOX COMPUTER DATA LINES SYSTEM E GND ENGINE JUNCTION BOX FUSE 1 FUSE LINK 17 GRY/BRN WIRE GRY/PPL WIRE HOT AT ALL TIMES HS CAN-H HS CAN-L INSTRUMENT CLUSTER ISO LEFT FRONT INITIATOR LEFT FRONT TIRE SENSOR LEFT REAR INITIATOR LEFT REAR TIRE SENSOR MOST IN MOST OUT MS CAN-H MS CAN-L NCA WIRE ORG/ WIRE PPL/BRN WIRE RADIO FREQUENCY RECEIVER (RF) RED/BLU WIRE RIGHT FRONT INITIATOR RIGHT FRONT TIRE SENSOR RIGHT REAR INITIATOR RIGHT REAR TIRE SENSOR SPARE TIRE SENSOR TOUCH SCREEN DISPLAY YEL WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/WHT WIRE

Go to component -> Warning systems circuit -> ORG/ WIRE
