Land Rover Discovery IV (2009-2013) navigation update socket Wiring diagrams

This page contains all the electrical diagrams for the component. navigation update socket, in which he is found in the car Land Rover Discovery IV (2009-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram navigation update socket for Land Rover Discovery IV (2009-2013) (1 of 2)

Get lifetime access to Land Rover Discovery IV (2009-2013)

-VE AM/FM DIVERSITY ANTENNA AMPLIFIER ANT PWR AON AOP AUDIO HEAD UNIT AUX L + AUX R + AV INPUT PANEL B/ON BLK WIRE BLU WIRE BODY CONTROL MODULE (BCM) BOP BRN/BLU WIRE BRN/GRY WIRE CENTRAL JUNCTION BOX COMP- UTER DATA LINES SYSTEM COMPUTER DATA LINES SYSTEM CTRL FM ANTENNA AMPLIFIER FM/TMC/ VICS FUSE 40 FUSE 64 FUSE 67 FUSE 68 GPS GPS ANTENNA GRN/PNK WIRE GRY/BLK WIRE GRY/RED WIRE HOT AT ALL TIMES INFOTAINMENT RELAY LOWER INTEGRATED CONTROL PANEL MIC - MIC SHIELD MOST IN MOST OUT MS CAN-H MS CAN-L NAVIGATION UPDATE SOCKET NCA WIRE ORG/ WIRE POWER PPL PPL RF IN PPL RF OUT PPL W/O IBOC PPL/BLU WIRE PPL/WHT WIRE RED WIRE RED/BLU WIRE RELAY RF IN RF INPUT RF OUT SCR SWS SWS GND TOUCH SCREEN DISPLAY TV VIDEO W/ IBOC W/ VEHICLE INFORMATION CONTROL SYSTEM W/O VEHICLE INFORMATION CONTROL SYSTEM WHT WIRE YEL/BLU WIRE YEL/WHT WIRE

Go to component -> Navigation circuit (1 of 4) -> NAVIGATION UPDATE SOCKET
