Land Rover Discovery IV (2009-2013) direction indicator switch Wiring diagram
This page shows the only wiring diagram for the component.direction indicator switch, which is found in the car Land Rover Discovery IV (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram direction indicator switch (1 of 1)
BACKUP LAMP CIRCUIT
BLK WIRE
BLK/GRN WIRE
BLU WIRE
BLU/RED WIRE
BODY CONTROL MODULE (BCM)
BRAKE PEDAL SWITCH
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/WHT WIRE
CENTRAL JUNCTION BOX
COMPUTER DATA LINES SYSTEM
DIRECTION INDICATOR SWITCH
DRIVER DOOR MODULE
ELECTRIC BRAKE TRAILER MODULE
ENGINE CONTROL MODULE (ECM)
ENGINE JUNCTION BOX
ENGINE RUN FET
FUSE 14
FUSE 24
FUSE 25
FUSE 27
FUSE 54
FUSE LINK 15
FUSE LINK 16
FUSE LINK 6
GRN WIRE
GRN/PPL WIRE
GRN/RED WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
HOT W/ ACCESSORY SOCKET RELAY ENERGIZED
HS CAN-H
HS CAN-L
IGN
INSTRUMENT CLUSTER
LEFT FRONT SIDE REPEATER LAMP
LEFT TURN SIGNAL IND
LH IND/STOP
MS MS RH CAN CAN IND IND
ORG/ WIRE
PASSENGER DOOR MODULE
PNK/WHT WIRE
POSITION LAMP RELAY
PPL/GRN WIRE
PPL/YEL WIRE
REAR WIPER TRAILER RELAY
RED WIRE
RED/BLK WIRE
RED/ORG WIRE
RED/WHT WIRE
REV
RH IND/STOP
RIGHT FRONT SIDE REPEATER LAMP
RIGHT TURN SIGNAL IND
STEERING COLUMN LIGHTING SWITCH
TAIL
TO LEFT REAR IND FET (DIAGRAM 2 OF 2)
TO RIGHT IND FET (DIAGRAM 2 OF 2)
TRAILER PICK-UP (4 PIN)
TRAILER PICK-UP (7 PIN)
TRAILER SOCKET RELAY
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/WHT WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> DIRECTION INDICATOR SWITCH
