Car Wiring Diagrams for Parking assistant circuit for Land Rover Discovery III (2004-2009)

BLK WIRE BLU WIRE BRN WIRE BRN/BLU WIRE BRN/PNK WIRE CENTER FACIA PACK SWITCH CENTRAL JUNCTION BOX COMPUTER DATA LINES SYSTEM FRONT PDC SWITCH FUSE 36 GRN WIRE HOT IN RUN LEFT FRONT INNER PARKING AID SENSOR LEFT FRONT OUTER PARKING AID SENSOR LEFT REAR INNER PARKING AID SENSOR LEFT REAR OUTER PARKING AID SENSOR LT GRN/RED WIRE PARKING AID CONTROL MODULE REAR PARKING AID SPEAKER RED WIRE RED/GRY WIRE RED/LT GRN WIRE RIGHT FRONT INNER PARKING AID SENSOR RIGHT FRONT OUTER PDC SENSOR RIGHT REAR INNER PARKING AID SENSOR RIGHT REAR OUTER PARKING AID SENSOR YEL WIRE YEL/BLU WIRE YEL/RED WIRE YEL/WHT WIRE
