Land Rover Discovery III (2004-2009) transfer control box module Wiring diagram
This page shows the only wiring diagram for the component.transfer control box module, which is found in the car Land Rover Discovery III (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram transfer control box module (1 of 1)
4 PIN
ABS MODULE (LEFT REAR OF ENGINE COMPT)
ANTI-LOCK BRAKES SYSTEM
BACKUP LAMPS CIRCUIT
BATTERY JUNCTION BOX
BLK WIRE
BLK/GRN WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
CENTER FACIA PACK SWITCH
CENTRAL JUNCTION BOX
COMPUTER DATA LINES SYSTEM
EARTH
FROM FUSE LINK 16 (DIAGRAM 1 OF 2)
FUSE 15
FUSE 22
FUSE 6
FUSE 8
FUSE LINK 6
GENERIC ELECTRONIC MODULE
GRN WIRE
GRN/BRN WIRE
GRN/ORG WIRE
GRN/PPL WIRE
GRN/RED WIRE
GRN/WHT WIRE
HAZARD WARNING SWITCH
HEADLIGHTS SYSTEM
HIGH MOUNTED STOP LAMP
HILL DESCENT RELAY
HOT AT ALL TIMES
HOT IN RUN
IGN
LEFT FRONT SIDE REPEATER LAMP
LEFT IND FET
LEFT REAR GUARD FOG LAMP
LEFT REAR SIDE MARKER LAMP
LEFT REVERSE LAMP
LEFT STOP LAMP
LEFT TAIL- LAMPS
LEFT TRAILER IND FET
LH IND/STOP
LT GRN/RED WIRE
NCA WIRE
NUMBER PLATE, TAIL DOOR SWITCH LAMP
ORG/ WIRE
PLATE LAMP LICENSE
PNK/WHT WIRE
PPL/GRN WIRE
RED WIRE
RED/BLK WIRE
RED/ORG WIRE
RED/YEL WIRE
REV
REVERSE LAMP RELAY
RH IND/STOP
RIGHT FRONT SIDE REPEATER LAMP
RIGHT IND FET
RIGHT REAR GUARD FOG- LAMP
RIGHT REAR SIDE MARKER LAMP
RIGHT REVERSE LAMP
RIGHT STOP LAMP
RIGHT TAIL- LAMPS
STOP LAMP SWITCH
TAIL
TRAILER ELECTRIC BRAKE MODULE
TRAILER PICKUP
TRAILER REAR WIPER RELAY
TRAILER RELAY
TRANSFER CONTROL BOX MODULE
TURN SIGNAL INDICATOR/ HAZARD FLASHER LAMP
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
Go to component -> Exterior lamps & trailer connector circuit (2 of 2) -> TRANSFER CONTROL BOX MODULE
