Land Rover Discovery III (2004-2009) terrain optimization switch Wiring diagrams
This page contains all the electrical diagrams for the component. terrain optimization switch, in which he is found in the car Land Rover Discovery III (2004-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
terrain optimization switch wiring diagram (1 of 2)
AIR SUSPENSION
AUTOMATIC GEARBOX SELECTOR INDICATOR LAMP
AUTOMATIC TEMPERATURE CONTROL MODULE
BLK WIRE
BRN WIRE
CAN (+)
CENTER CONSOLE SWITCH PACK
COMPUTER DATA LINES SYSTEM
DRIVER DOOR WINDOW SWITCH
ELECTRIC PARK BRAKE SWITCH (UNDER CENTER CONSOLE)
FROM FRONT CIGAR LIGHTER (DIAGRAM 1 OF 2)
FRONT INTERIOR LAMP
GRN/BLK WIRE
HI/LOW RATIO
HILL DECENT SWITCH
ISOLATION WINDOW LIFT SWITCH
LEFT "C" PILLAR)
LEFT HEADPHONE UNIT
LEFT REAR HEATED SEAT SWITCH
LEFT REAR WINDOW SWITCH
PASSENGER DOOR WINDOW SWITCH
RED WIRE
RED/BRN WIRE
RIGHT HEADPHONE UNIT
RIGHT REAR HEATED SEAT SWITCH
RIGHT REAR WINDOW SWITCH
ROOF OPENING PANEL CONTROL MODULE
SELECTOR MECHANISM (UNDER CENTER CONSOLE)
SUN ROOF SWITCH
TERRAIN OPTIMIZATION SWITCH
W/ HEADPHONES
W/O HEADPHONES
WATERFALL LIGHTING LED
YEL/BLU WIRE
YEL/WHT WIRE
Go to component -> Instrument illumination circuit (2 of 2) -> TERRAIN OPTIMIZATION SWITCH
terrain optimization switch wiring diagram (2 of 2)
ABS MODULE
AIR SUSPENSION CONTROL MODULE
BLK WIRE
CAN L
CENTER CONSOLE SWITCH PACK
CENTRAL JUNCTION BOX
COMPUTER DATA LINES SYSTEM
ENGINE CONTROL MODULE
FUSE 24
HOT IN RUN
IGN
INSTRUMENT CLUSTER SYSTEM
PARKING BRAKE MODULE
REAR DIFFERENTIAL CONTROL MODULE
RED WIRE
TERRAIN OPTIMIZATION SWITCH
TRANSFER BOX CONTROL MODULE
TRANSMISSION CONTROL MODULE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/WHT WIRE
Go to component -> Terrain response circuit -> TERRAIN OPTIMIZATION SWITCH
