Trunk, tailgate, fuel door circuits for Land Rover Discovery II (1998-2004)
Trunk, tailgate, fuel door circuits
BLK BLK WIRE
BLK WIRE
BODY CONTROL UNIT (UNDER RIGHT SIDE OF DASH)
ENGINE COMPARTMENT FUSE BOX (RIGHT FRONT OF ENGINE COMPARTMENT)
FUEL FLAP RELEASE SOLENOID (BEHIND RIGHT REAR TRIM PANEL)
FUEL FLAP RELEASE SWITCH
FUSE 13
FUSE 2
GRY PPL/ WIRE
HOT AT ALL TIMES
PASSENGER COMPARTMENT FUSE BOX (UNDER LEFT SIDE OF DASH)
PPL/BRN WIRE
PPL/GRY WIRE
PPL/RED WIRE
RED/BLU WIRE
