Car Wiring Diagrams for Charging circuit for Land Rover Discovery II (1998-2004)

ALTERNATOR/ GENERATOR BATTERY BLK WIRE BRN WIRE FUSE 27 FUSE LINK 1 GROUND HOT IN RUN OR START IGNITION/ NO CHARGE WARNING LAMP INDICATOR INSTRUMENT CLUSTER LT GRN WIRE PASSENGER COMPARTMENT FUSE BOX (UNDER LEFT SIDE OF DASH) POWER DISTRIBUTION SYSTEM RED WIRE YEL WIRE
