Land Rover Discovery II (1998-2004) Power & heated seat circuit

1 3 PNK WIRE AUXILIARY CIRCUITS RELAY BACKREST FORWARD BACKREST REARWARD BCU SEAT SWITCH BLK WIRE BLU WIRE BLU/GRY WIRE BLU/PNK WIRE BODY CONTROL UNIT (UNDER RIGHT SIDE OF DASH) BRN/ GRN WIRE BRN/PPL WIRE BRN/YEL WIRE ENGINE COMPARTMENT FUSE BOX (RIGHT FRONT OF ENGINE COMPARTMENT) FORWARD/ REARWARD MOTOR FUSE 15 FUSE 2 FUSE 26 FUSE 3 FUSE 4 FUSIBLE LINK 1 FUSIBLE LINK 5 FUSIBLE LINK 7 GRN/YEL WIRE GRY WIRE HOT AT ALL TIMES HOT IN ACC OR RUN J/C 0708 (BEHIND CENTER CONSOLE) LEFT POWER SEAT RELAY LEFT SATELLITE FUSE BOX (UNDER LEFT FRONT SEAT) FUSE 3 LEFT SEAT LEFT SEAT HEATER SWITCH LEFT SEAT RIGHT SEAT LT GRN WIRE LT GRN/WHT WIRE LUMBAR DEFLATE LUMBAR INFLATE LUMBAR PUMP (LEFT/RIGHT) ORG/ WIRE ORG/PPL WIRE ORG/WHT WIRE PASSENGER COMPARTMENT FUSE BOX (UNDER LEFT SIDE OF DASH) PNK WIRE PNK/WHT WIRE PPL PPL GRY WIRE PPL/ BRN WIRE PPL/BLK WIRE PPL/GRY WIRE RED WIRE RIGHT POWER SEAT RELAY RIGHT SATELLITE FUSE BOX (UNDER RIGHT FRONT SEAT) FUSE 2 RIGHT SEAT RIGHT SEAT HEATER SWITCH SEAT CUSHION HEATER (LEFT /RIGHT) SEAT FORWARD SEAT FRONT DN SEAT FRONT UP SEAT FRONT UP-DOWN MOTOR SEAT HEATER MODULE (LEFT/RIGHT) SEAT PACK SWITCH (LEFT/RIGHT) SEAT REAR DN SEAT REAR UP SEAT REAR UP-DOWN MOTOR SEAT REARWARD SEAT SQUAB HEATER (LEFT/RIGHT) SEAT-BACK RECLINE MOTOR WHT WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE
