Power door lock circuit for Land Rover Discovery II (1998-2004)
Power door lock circuit (1 of 2)
1 4 5 6 18 19 22 PNK WIRE
BLK BLK WIRE
BLK WIRE
BLK/BRN WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BODY CONTROL UNIT (UNDER RIGHT SIDE OF DASH)
BRN/BLK WIRE
BRN/GRY WIRE
CENTRAL DOOR LOCKING RELAYS
ENGINE COMPARTMENT FUSE BOX (RIGHT FRONT OF ENGINE COMPARTMENT)
FUSE 1
FUSE 13
FUSE 20
GRN/BLU WIRE
GRY/PNK WIRE
GRY/RED WIRE
HOT AT ALL TIMES
INERTIA FUEL CUT-OFF SWITCH (ON LEFT SIDE OF FIREWALL)
INSTRUMENT CLUSTER
INTELLIGENT DRIVER MODULE
PASSENGER COMPARTMENT FUSE BOX (UNDER LEFT SIDE OF DASH)
PASSIVE COIL (ON RIGHT SIDE OF STEERING COLUMN)
PNK WIRE
PNK/GRY WIRE
PNK/PPL WIRE
PNK/RED WIRE
PPL
PPL/BRN WIRE
PPL/GRY WIRE
RADIO FREQUENCY RECEIVER (BEHIND CENTER OF HEADLINER)
WHT/GRN WIRE
YEL/PNK WIRE
Power door lock circuit (2 of 2)
4 AMP 2 AMP
BLK BLK WIRE
BLK WIRE
BLU/GRN WIRE
BLU/GRY WIRE
CENTRAL DOOR LOCKING SWITCH
LEFT DOOR LOCK MOTOR SWITCH
LEFT FRONT CDL MOTOR LEFT FRONT SUPERLOCK MOTOR
LEFT FRONT DOOR LOCK MOTOR
LEFT REAR CDL MOTOR LEFT REAR SUPERLOCK MOTOR
LEFT REAR DOOR LOCK MOTOR
LOCK UNLOCK
PNK/GRY WIRE
PNK/PPL WIRE
PNK/RED WIRE
RIGHT FRONT CDL MOTOR RIGHT FRONT SUPERLOCK MOTOR
RIGHT FRONT DOOR LOCK MOTOR
RIGHT REAR CDL MOTOR RIGHT REAR SUPERLOCK MOTOR
RIGHT REAR DOOR LOCK MOTOR
TAILDOOR LOCK MOTOR
TAILGATE CDL MOTOR TAILGATE SUPERLOCK MOTOR
YEL/PNK WIRE
