Land Rover Discovery II (1998-2004) header 0286 Wiring diagram
This page shows the only wiring diagram for the component.header 0286, which is found in the car Land Rover Discovery II (1998-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram header 0286 (1 of 1)
AIR BAG DCU (BELOW CENTER CONSOLE)
BLK WIRE
BRN WIRE
BRN/RED WIRE
DIAGNOSTIC SOCKET (PARTIAL) (BEHIND LEFT SIDE OF DASH, RIGHT OF STEERING COLUMN)
DRIVER'S AIR BAG
FUSE 35
GRN WIRE
HEADER 0286
HOT WITH IGNITION SWITCH IN POSITION 1
INDICATOR EARTH IGNITION
INSTRUMENT PACK
LEFT PRETENSIONER (UNDER LEFT FRONT SEAT)
NCA WIRE
ORG/ WIRE
ORG/RED WIRE
PASSENGER COMPARTMENT FUSE BOX (UNDER LEFT SIDE OF DASH)
PASSENGER'S AIR BAG
PNK K LINE PRETEN FEED PRETEN RTN WIRE
PNK WIRE
PRETEN FEED PRETEN RTN
RED WIRE
RED/YEL WIRE
RIGHT PRETENSIONER (UNDER RIGHT FRONT SEAT)
ROTARY COUPLER
SRS WARNING LAMP
WHT WIRE
WHT/YEL WIRE
YEL/RED WIRE
Go to component -> Supplemental restraint circuit -> HEADER 0286
