Land Rover Discovery II (1998-2004) engine management ind Wiring diagram
This page shows the only wiring diagram for the component.engine management ind, which is found in the car Land Rover Discovery II (1998-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram engine management ind (1 of 1)
ABS IND.
ACE IND
ACTIVE CORNERING ENHANCEMENT ECU (UNDER RIGHT SIDE OF DASH)
BLK LT GRN/ WIRE
BLK WIRE
BLK/BLU WIRE
BLK/GRY WIRE
BLK/LT GRN WIRE
BLK/ORG WIRE
BLU WIRE
BLU/GRY WIRE
BODY CONTOL UNIT (UNDER RIGHT SIDE OF DASH)
BRAKE FLUID LEVEL SWITCH (TOP OF BRAKE FLUID RESERVOIR)
BRN PPL/ WIRE
BRN/YEL WIRE
CLOCK
COMPUTER DATA LINES SYSTEM
DIFFERENTIAL LOCK IND
DIFFERENTIAL LOCK UNIT
ELECTRONIC AUTO TRANS ECU (UNDER LEFT FRONT SEAT)
ENGINE COMPARTMENT FUSE BOX (RIGHT FRONT OF ENGINE COMPT) FUSE 14
ENGINE CONTROL MODULE (UNDER RIGHT SIDE OF DASH)
ENGINE MANAGEMENT IND
FUEL GAUGE LOW FUEL IND
FUEL TANK UNIT (TOP OF FUEL TANK)
FUSE 27 FUSE 25
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/GRY WIRE
GRY WIRE
GRY/PNK WIRE
HANDBRAKE SWITCH (UNDER CENTER CONSOLE)
HANDBRAKE/ FLUID LEVEL IND
HDC IND
HIGH TEMP IND
HILL DESCENT IND
HOT AT ALL TIMES
HOT IN RUN OR START
IGNITION/NO CHARGE IND
INSTRUMENT CLUSTER
INTELLIGENT DRIVER MODULE FUSE 16 FUSE 20
J/C
J/C J/C (UNDER LEFT SIDE OF DASH) (BEHIND LOWER LEFT END OF DASH)
LH TURN SIGNAL IND
LT GRN WIRE
LT GRN/ PPL WIRE
LT GRN/PPL WIRE
MAIN BEAM IND
MANUAL IND
OFF ROAD MODE SWITCH
OFF-ROAD IND
OIL PRESSURE IND
OIL PRESSURE SWITCH (LOWER RIGHT SIDE OF ENGINE, NEAR OIL FILTER) J/C
OIL TEMPERATURE SWITCH
OVERSPEED IND
PASSENGER COMPARTMENT FUSE BOX (UNDER LEFT SIDE OF DASH)
PNK/ GRN WIRE
PNK/ ORG WIRE
PNK/BLK WIRE
PNK/GRN WIRE
PNK/ORG WIRE
PNK/WHT WIRE
PPL
PPL/ BRN WIRE
PPL/ORG WIRE
PPL/PNK WIRE
RED/GRY WIRE
RESISTOR
RH TURN SIGNAL IND
SEAT BELT IND
SELF-LEVELING/ ABS (SLABS) ECU (UNDER RIGHT SIDE OF DASH)
SLS IND
SPEEDOMETER
SPORT IND
SRS IND
STARTING/ CHARGING SYSTEM
SUPPLEMENTAL RESTRAINT SYSTEM
TACHOMETER
TEMPERATURE GAUGE
THEFT ALARM LED
TRACTION CONTROL IND
TRAILER TOW IND
TRANS TRANS OIL IND OIL IND
TRANSFER IN NEUTRAL IND
TRANSMISSION OIL TEMPERATURE SWITCH (ON LEFT SIDE OF TRANSFER BOX)
WHT BRN WIRE
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRY WIRE
WHT/ORG WIRE
WHT/PNK WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Instrument cluster circuit -> ENGINE MANAGEMENT IND
