Radio circuit, 6-speaker system for Land Rover Discovery Sport I (2014-2019)

AM FM SCN AM FM SIG AUDIO HEAD UNIT AUX L + AUX R + AUX SHIELD BAND 3 GND BAND 3 SIG BLK WIRE BLK/PPL WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/GRN WIRE BRN WIRE BRN/BLU WIRE BRN/PPL WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DIAG JAE CONN FERRITE CORE FUSE 2 FUSE 5 GRN WIRE GROUND GRY/PPL WIRE GRY/YEL WIRE HOT W/ RELAY 1 ENERGIZED L-BAND GND L-BAND SIG LEFT FRONT DOOR BASS SPEAKER LEFT FRONT TWEETER LEFT REAR DOOR SPEAKER LF LOW/HI - LR LOW MIC - MS CAN H (CO) ANTENNA PWR MS CAN L (CO) MULTI INFORMATION DISPLAY UNIT NCA WIRE ORG/ WIRE POWER PPL PPL/GRN WIRE PWR GND QUIESCENT CURRENT CONTROL MODULE RED WIRE RF LOW/HI - RF OUT RIGHT FRONT DOOR BASS SPEAKER RIGHT FRONT TWEETER RIGHT REAR DOOR SPEAKER RR LOW - SHIELD WHT WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/ORG WIRE WHT/PPL WIRE YEL WIRE YEL/GRN WIRE YEL/ORG WIRE

AM/FM ANTENNA AMPLIFIER (TOP RIGHT SIDE OF TAILDOOR) AUDIO LIN BLU WIRE BLU/GRN WIRE BRN/PPL WIRE COAX COMPUTER DATA LINES SYSTEM FERRITE CORE FM ANTENNA AMPLIFIER (TOP LEFT SIDE OF TAILDOOR) FRONT OVERHEAD CONSOLE GLOBAL POSITIONING SYSTEM (GPS) ANTENNA GPS IN GND GPS IN SIG GPS OUT GND GPS OUT SIG GPS SCRN GPS SIG GPS SIGNAL SPLITTER GRN/WHT WIRE GRY/YEL WIRE HS CAN-H HS CAN-L IPC LIN LEFT STEERING WHEEL SWITCHPACK MIC - MIC SCR MICROPHONE MODE SWITCH NCA WIRE PHONE END SWITCH PHONE SEND SWITCH PPL PWR RED WIRE SEEK DOWN SWITCH SEEK UP SWITCH STEERING WHEEL MODULE TELEMATIC CONTROL MODULE VOLUME SWITCH W/ TELEMATICS W/O TELEMATICS WHT WIRE WHT/GRN WIRE WHT/RED WIRE YEL/GRN WIRE YEL/ORG WIRE

AUDIO HEAD UNIT AUDIO VIDEO INPUT OUTPUT PANEL BLK WIRE BLK/PPL WIRE BLU WIRE BLU/GRN WIRE BRN WIRE CVBS GND CVBS SIG GPS SHIELD GPS SIG HOST DIAGNOSTIC ILLUMINATION IMAGE PROCESSING MODULE LEVEL B LEVEL C W/ NAVIGATION W/O NAVIGATION LH - LH/RH NCA WIRE OTG DIAGNOSTIC OTG HOST DATA - POWER GND PPL PWR ENABLE REAR VIEW CAMERA RED WIRE RH- SCR SDARS SDARS ANTENNA SDARS SCRN SDARS SHIELD SDARS SIG SPARE USB DATA 0 (+) SHIELD 2 USB DATA 0 (-) CHIP ENABLE USB DATA 1 (+) SHIELD USB DATA 1 (+) SHIELD 1 USB DATA 1 (-) NC USB DATA 1- USB OTG DATA + USB SHIELD USB V BUS VBATT VID OUT WHT/GRN WIRE YEL/GRN WIRE
