Telematics circuit for Land Rover Discovery Sport I (2014-2019)

B-CALL ACTIVATED LED B-CALL BACKLIGHT B-CALL BTN BACKLIGHT B-CALL LED 1 BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/GRY WIRE BLU WIRE BRN/YEL WIRE BTN DIAGNOSTIC BTN INPUT COMM BTN SW RTN BTN'S DIAGNOSTIC O/P COMPUTER DATA LINES SYSTEM CRASH SIG E-CALL BACKLIGHT E-CALL BTN BACKLIGHT E-CALL LED 1 ECALL ACTIVATED LED ECALL BTN- ECALL/BCALL BTN FRONT OVERHEAD CONSOLE GRN/ORG WIRE GRN/RED WIRE GRY/BLU WIRE HOT AT ALL TIMES HS CAN-H HS CAN-L LED 2 LED O/P COMMON MIC - MIC SCR MS CAN-H MS CAN-L NCA WIRE REAR JUNCTION BOX SPEAKER SUPPLEMENTAL RESTRAINTS SYSTEM TCU LED RTN TELEMATIC CONTROL MODULE TELEMATICS SPEAKER W/ CONTROL TOUCH PLUS W/ CONTROL TOUCH, 6-SPEAKER SYSTEM YEL/GRN WIRE YEL/ORG WIRE YEL/PPL WIRE

AUDIO HEAD UNIT BLK WIRE BLU WIRE DATA DIAGNOSTICS 1 DIAGNOSTICS 2 GLOBAL POSITIONING SYSTEM (GPS) ANTENNA GND SCREEN GPS IN GND GPS IN SIG GPS OUT GND GPS OUT SIG GPS SCRN GPS SIG GPS SIGNAL SPLITTER GRN WIRE GSM ANTENNA INTEGRATED AUDIO MODULE MBM ANT SIG MIC - NCA WIRE RED WIRE SCR SHIELD SIG TELEMATIC CONTROL MODULE W/ GPS SIGNAL SPLITTER W/O GPS SIGNAL SPLITTER WHT WIRE YEL WIRE YEL/GRN WIRE
