Land Rover Discovery Sport I (2014-2019) w/ control touch plus w/o control touch plus Wiring diagram
This page shows the only wiring diagram for the component.w/ control touch plus w/o control touch plus, which is found in the car Land Rover Discovery Sport I (2014-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ control touch plus w/o control touch plus (1 of 1)
AUDIO GND
AUDIO L+
AUDIO LEFT
AUDIO R-
AUDIO RIGHT
BLK/GRY WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BRN WIRE
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
CVBS
CVBS VIDEO OUT CVBS VIDEO OUT GND
DATA (-) GND
DATA NEG
DATA POS
DATA SHIELD
FUSE 4
FUSE 6
GRN WIRE
HLDR GND
HOT W/ RELAY 1 ENERGIZED
LVDS OUT - PPL LVDS OUT + SCR
MOST IN
MOST OUT
MS CAN-H
MS CAN-L
NCA WIRE
ORG/ WIRE
PPL
QUIESCENT CURRENT CONTROL MODULE
REAR CONSOLE PORTABLE DEVICE INTERFACE
REAR SEAT ENTERTAINMENT MODULE
RED WIRE
SIG
SUPP HLDF L/R
TOUCH- SCREEN
USB DATA -
USB GND
USB SHIELD
VIDEO GND
VIDEO IN -
VIDEO IN GND
VIDEO IN NEG
VIDEO IN POS SCR VIDEO IN SCR
VIDEO+
W/ CONTROL TOUCH PLUS W/O CONTROL TOUCH PLUS
W/ TELEVISION CONTROL MODULE W/O TELEVISION CONTROL MODULE
W/ TV
W/O TV
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
YEL WIRE
YEL/GRY WIRE
Go to component -> Rear seat entertainment circuit (1 of 2) -> W/ CONTROL TOUCH PLUS W/O CONTROL TOUCH PLUS
