Land Rover Discovery Sport I (2014-2019) mir ssr right Wiring diagram
This page shows the only wiring diagram for the component.mir ssr right, which is found in the car Land Rover Discovery Sport I (2014-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mir ssr right (1 of 1)
BLK/GRN WIRE
BLU WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BLU/WHT WIRE
COMPUTER DATA LINES SYSTEM
DRIVER SIDE DOOR MIRROR
EXT IGN
GENERAL PROXIMITY SENSOR MODULE
GRN/BLU WIRE
GRN/WHT WIRE
HOT W/ EXTENDED IGNITION RELAY ENERGIZED
HS CAN-H
HS CAN-L
MIR SSR LEFT
MIR SSR RIGHT
PASSENGER SIDE DOOR MIRROR
PPL/GRY WIRE
REAR JUNCTION BOX
RED WIRE
SSR GND
SSR LEFT GND
SSR LEFT PWR
SSR PWR
SSR RIGHT GND
SSR RIGHT PWR
SSR SIG
YEL/GRN WIRE
YEL/ORG WIRE
Go to component -> Vehicle proximity notification circuit -> MIR SSR RIGHT
