Land Rover Discovery Sport I (2014-2019) level b level c w/ navigation w/o navigation Wiring diagrams

This page contains all the electrical diagrams for the component. level b level c w/ navigation w/o navigation, in which he is found in the car Land Rover Discovery Sport I (2014-2019). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram level b level c w/ navigation w/o navigation (1 of 4)

Wiring diagram level b level c w/ navigation w/o navigation for Land Rover Discovery Sport I (2014-2019) (1 of 4)

Get access

AUDIO HEAD UNIT AUDIO VIDEO INPUT OUTPUT PANEL BLK WIRE BLK/PPL WIRE BLU WIRE BLU/GRN WIRE BRN WIRE CVBS GND CVBS SIG GPS SHIELD GPS SIG HOST DIAGNOSTIC ILLUMINATION IMAGE PROCESSING MODULE LEVEL B LEVEL C W/ NAVIGATION W/O NAVIGATION LH - LH/RH NCA WIRE OTG DIAGNOSTIC OTG HOST DATA - POWER GND PPL PWR ENABLE REAR VIEW CAMERA RED WIRE RH- SCR SDARS SDARS ANTENNA SDARS SCRN SDARS SHIELD SDARS SIG SPARE USB DATA 0 (+) SHIELD 2 USB DATA 0 (-) CHIP ENABLE USB DATA 1 (+) SHIELD USB DATA 1 (+) SHIELD 1 USB DATA 1 (-) NC USB DATA 1- USB OTG DATA + USB SHIELD USB V BUS VBATT VID OUT WHT/GRN WIRE YEL/GRN WIRE

Go to component -> Navigation circuit, 6-speaker system (3 of 3) -> LEVEL B LEVEL C W/ NAVIGATION W/O NAVIGATION

Wiring diagram level b level c w/ navigation w/o navigation (2 of 4)

Wiring diagram level b level c w/ navigation w/o navigation for Land Rover Discovery Sport I (2014-2019) (2 of 4)

Get access

AUDIO HEAD UNIT AUDIO VIDEO INPUT OUTPUT PANEL BLK WIRE BLK/PPL WIRE BLU WIRE BLU/GRN WIRE BRN WIRE CVBS GND CVBS SIG GPS SHIELD GPS SIG HOST DIAGNOSTIC ILLUMINATION IMAGE PROCESSING MODULE LEVEL B LEVEL C W/ NAVIGATION W/O NAVIGATION LH - LH/RH NCA WIRE OTG DIAGNOSTIC OTG HOST DATA - POWER GND PPL PWR ENABLE REAR VIEW CAMERA RED WIRE RH- SCR SDARS SDARS ANTENNA SDARS SCRN SDARS SHIELD SDARS SIG SPARE USB DATA 0 (+) SHIELD 2 USB DATA 0 (-) CHIP ENABLE USB DATA 1 (+) SHIELD USB DATA 1 (+) SHIELD 1 USB DATA 1 (-) NC USB DATA 1- USB OTG DATA + USB SHIELD USB V BUS VBATT VID OUT WHT/GRN WIRE YEL/GRN WIRE

Go to component -> Navigation circuit, w/ control touch (4 of 4) -> LEVEL B LEVEL C W/ NAVIGATION W/O NAVIGATION

Wiring diagram level b level c w/ navigation w/o navigation (3 of 4)

Wiring diagram level b level c w/ navigation w/o navigation for Land Rover Discovery Sport I (2014-2019) (3 of 4)

Get access

AUDIO HEAD UNIT AUDIO VIDEO INPUT OUTPUT PANEL BLK WIRE BLK/PPL WIRE BLU WIRE BLU/GRN WIRE BRN WIRE CVBS GND CVBS SIG GPS SHIELD GPS SIG HOST DIAGNOSTIC ILLUMINATION IMAGE PROCESSING MODULE LEVEL B LEVEL C W/ NAVIGATION W/O NAVIGATION LH - LH/RH NCA WIRE OTG DIAGNOSTIC OTG HOST DATA - POWER GND PPL PWR ENABLE REAR VIEW CAMERA RED WIRE RH- SCR SDARS SDARS ANTENNA SDARS SCRN SDARS SHIELD SDARS SIG SPARE USB DATA 0 (+) SHIELD 2 USB DATA 0 (-) CHIP ENABLE USB DATA 1 (+) SHIELD USB DATA 1 (+) SHIELD 1 USB DATA 1 (-) NC USB DATA 1- USB OTG DATA + USB SHIELD USB V BUS VBATT VID OUT WHT/GRN WIRE YEL/GRN WIRE

Go to component -> Radio circuit, 6-speaker system (3 of 3) -> LEVEL B LEVEL C W/ NAVIGATION W/O NAVIGATION

Wiring diagram level b level c w/ navigation w/o navigation (4 of 4)

Wiring diagram level b level c w/ navigation w/o navigation for Land Rover Discovery Sport I (2014-2019) (4 of 4)

Get access

AUDIO HEAD UNIT AUDIO VIDEO INPUT OUTPUT PANEL BLK WIRE BLK/PPL WIRE BLU WIRE BLU/GRN WIRE BRN WIRE CVBS GND CVBS SIG GPS SHIELD GPS SIG HOST DIAGNOSTIC ILLUMINATION IMAGE PROCESSING MODULE LEVEL B LEVEL C W/ NAVIGATION W/O NAVIGATION LH - LH/RH NCA WIRE OTG DIAGNOSTIC OTG HOST DATA - POWER GND PPL PWR ENABLE REAR VIEW CAMERA RED WIRE RH- SCR SDARS SDARS ANTENNA SDARS SCRN SDARS SHIELD SDARS SIG SPARE USB DATA 0 (+) SHIELD 2 USB DATA 0 (-) CHIP ENABLE USB DATA 1 (+) SHIELD USB DATA 1 (+) SHIELD 1 USB DATA 1 (-) NC USB DATA 1- USB OTG DATA + USB SHIELD USB V BUS VBATT VID OUT WHT/GRN WIRE YEL/GRN WIRE

Go to component -> Radio circuit, w/ control touch (4 of 4) -> LEVEL B LEVEL C W/ NAVIGATION W/O NAVIGATION
