Front heated seats circuit for Kia Telluride I facelift (2022-2024)

B-CAN HIGH B-CAN LOW BLK WIRE BLK/ORG WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BRN WIRE BRN/BLK WIRE COMPUTER DATA LINES SYSTEM DRIVER SEAT WARMER SWITCH FRONT SEAT WARMER CONTROL MODULE GRN/ORG WIRE GRY WIRE GRY/ORG WIRE HIGH IND HOT AT ALL TIMES HTR B+ ICU JUNCTION BLOCK ICU-C ICU-G ILL LF HTR HIGH IND LF HTR LOW IND LF HTR MID IND LF HTR SW SIG LOW IND LT GRN WIRE MEMORY PWR MID IND MODULE 6 FUSE NTC (-) HTR GND NTC- ON/START INPUT ORG/ WIRE ORG/BLK WIRE PNK WIRE PNK/BLK WIRE RED WIRE RED/ORG WIRE RELAY ENERGIZED RF HTR HIGH IND RF HTR LOW IND RF HTR MID IND RF HTR SW SIG S/HEATER FRT FUSE WHT WIRE WHT/ORG WIRE YEL WIRE YEL/ORG WIRE

BLK WIRE BLK/ORG WIRE BLU WIRE BLU/BLK WIRE BRN WIRE BRN/BLK WIRE DRIVER SEAT WARMER (BACK) DRIVER SEAT WARMER (CUSHION) GRN WIRE GRN/ORG WIRE GRY WIRE HIGH IND HTR B+ HTR GND ILL LOW IND LT GRN WIRE MID IND NTC- ORG/ WIRE ORG/BLK WIRE PASSENGER SEAT WARMER (BACK) PASSENGER SEAT WARMER (CUSHION) PASSENGER SEAT WARMER SWITCH PNK WIRE RED WIRE WHT WIRE YEL WIRE YEL/ORG WIRE
