Kia Telluride I facelift (2022-2024) t/sig lp sw sig lh Wiring diagrams
This page contains all the electrical diagrams for the component. t/sig lp sw sig lh, in which he is found in the car Kia Telluride I facelift (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram t/sig lp sw sig lh (1 of 2)
ADC (PULL DOWN)
ADC (PULL UP)
B+1 FUSE
B+1 INPUT
B+2 FUSE
B+2 INPUT
B-CAN HIGH
B-CAN LOW
BACKUP LAMP
BACKUP LAMP CIRCUIT
BLK WIRE
BLU WIRE
BRAKE LP LH
BRAKE LP RH
BRN WIRE
BRN/ORG WIRE
COMPUTER DATA LINES SYSTEM
E/R JUNCTION BLOCK
FR T/SIG LH
FR T/SIG RH
FRT TAIL EXT RH
FRT TURN SIG LP TELLTALE SW LH ICU-A
FRT TURN SIG LP TELLTALE SW RH
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRY WIRE
GRY/BLK WIRE
HAZ SW
HAZ SW IND
HAZARD SWITCH
HMSL
HOT AT ALL TIMES
ICU JUNCTION BLOCK (LEFT SIDE OF DASH)
ICU-A
ICU-B
ICU-C
ICU-C FRT TAIL EXT LH
ICU-F
ICU-G
IND
IPS 2
IPS 3
IPS 4
IPS 5
IPS 8
IPS 9
IPS CONTROL MODULE
LEFT REAR COMBINATION LAMP (IN) BACKUP, TAIL LAMP
LEFT REAR COMBINATION LAMP (OUT)
MULTI FUSE 1
MULTI FUSE 2
NCA WIRE
ORG/ WIRE
PNK WIRE
REAR TURN SIG LP TELLTALE SW LH ICU-C
REAR TURN SIG LP TELLTALE SW RH
RED WIRE
RIGHT REAR COMBINATION LAMP (IN) BACKUP, TAIL LAMP
RIGHT REAR COMBINATION LAMP (OUT)
RR TAIL LP
RR TAIL LP LH
SIDE MARKER LAMP
STOP LAMP
STOP LP SIG
T/SIG LP SW SIG LH
T/SIG LP SW SIG RH ICU-F
TAIL LAMP
TELLTALE
TURN LAMP
W/ INTEGRATED TYPE HEADLAMP
W/ SEPARATED TYPE HEADLAMP
WHT WIRE
WHT/BLK WIRE
WHT/ORG WIRE
YEL/BLK WIRE
YEL/ORG WIRE
Go to component -> Exterior lamps circuit, w/ led (1 of 3) -> T/SIG LP SW SIG LH
