Kia Telluride I facelift (2022-2024) rly low side Wiring diagram
This page shows the only wiring diagram for the component.rly low side, which is found in the car Kia Telluride I facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rly low side (1 of 1)
BATTERY
BATTERY JUNCTION BLOCK
BLK WIRE
BLU WIRE
BRN/BLK WIRE
E/R JUNCTION BLOCK
FEEDBACK SIG
GRN WIRE
GRN/ORG WIRE
IBU SSB
MOTOR CNTRL
ORG/ WIRE
P/N SWITCH
PNK WIRE
POWER DISTRIBUTION SYSTEM
RED/BLK WIRE
RLY
RLY HIGH SIDE
RLY LOW SIDE
SSB
SSB SWITCH 1
SSB SWITCH 2
START MOTOR
START RELAY
START SOLENOID
START/STOP BUTTON
TRANSAXLE RANGE SWITCH
WHT WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Starting circuit -> RLY LOW SIDE
