Kia Telluride I facelift (2022-2024) right turn signal lamp sw out Wiring diagram
This page shows the only wiring diagram for the component.right turn signal lamp sw out, which is found in the car Kia Telluride I facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right turn signal lamp sw out (1 of 1)
ASIC
B-CAN HIGH
B-CAN LOW
BLK WIRE
BLU WIRE
BRAKE SWITCH FUSE
BRK LIGHT SW
BRK SIG
BRK TEST SW
BRN/ORG WIRE
CLUSTER FUSE
COIL
COMPUTER DATA LINES SYSTEM
ESC UNIT ESC MODULE
FULL TURN RIGHT
GND (BCM)
GRN WIRE
GRN/BLK WIRE
GRY/ORG WIRE
HEADLAMP
HIGH MOUNTED STOP LAMP
HOT AT ALL TIMES
IBU
IBU FUSE
ICU JUNCTION BLOCK
ICU-A
ICU-G
LAN CHANGE LEFT FULL TURN LEFT
LAN CHANGE RIGHT
LEFT TURN SIGNAL LAMP SW OUT
LIGHT SW OUT
LIGHT SW SIG
MEMORY PWR
MIRRORS SYSTEM
MODULE 4 FUSE
MODULE 8 FUSE
MULTI- FUNCTION SWITCH
NCA WIRE
OFF
ON/START
ORG/ WIRE
RED WIRE
RELAY ENERGIZED
RIGHT TURN SIGNAL LAMP SW OUT
STOP LAMP SIG
STOP LAMP SWITCH
TAIL
TRAILER CONNECTOR
VIDEO SIG
WHT WIRE
WHT/ORG WIRE
WIP, LIGHT GND
YEL WIRE
Go to component -> Exterior lamps circuit, w/ led (3 of 3) -> RIGHT TURN SIGNAL LAMP SW OUT
