Kia Telluride I facelift (2022-2024) right map Wiring diagram
This page shows the only wiring diagram for the component.right map, which is found in the car Kia Telluride I facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right map (1 of 1)
B+1 FUSE
B-CAN HIGH
B-CAN LOW
BLK WIRE
BLU WIRE
BRN WIRE
BRN/ORG WIRE
CARGO LAMP
CENTER ROOM LAMP
COMPUTER DATA LINES SYSTEM
DOOR
E/R JUNCTION BLOCK
GRN WIRE
HOT AT ALL TIMES
IBU
LAMP
LED STABILITY PCB
LEFT MAP
LEFT REAR PERSONAL LAMP (W/ PANORAMA SUNROOF)
MULTI FUSE 2
OFF
ORG/ WIRE
OVERHEAD CONSOLE LAMP
POCKET LAMP
RIGHT MAP
RIGHT REAR PERSONAL LAMP (W/ PANORAMA SUNROOF)
ROOM
ROOM SIG
W/ LED
W/O LED
WHT WIRE
WHT/ORG WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (2 of 4) -> RIGHT MAP
