Kia Telluride I facelift (2022-2024) rear defogger switch input Wiring diagrams
This page contains all the electrical diagrams for the component. rear defogger switch input, in which he is found in the car Kia Telluride I facelift (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram rear defogger switch input (1 of 2)
A/C FUSE
B-CAN HIGH
B-CAN LOW
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
DEFOGGER
DRIVER DOOR MODULE
DRIVER POWER OUTSIDE MIRROR
DRIVER POWER OUTSIDE MIRROR (W/ MEMORY)
GRN WIRE
GRN/ORG WIRE
GROUND DISTRIBUTION SYSTEM
HOT AT ALL TIMES
ICU JUNCTION BLOCK
ICU-C
ICU-G
LIN
MCU
MODULE 11 FUSE
MODULE 4 FUSE
MODULE 8 FUSE
MSDI
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
OUTSIDE MIRROR CONTROL (IMS)
PASSENGER POWER OUTSIDE MIRROR
PASSENGER POWER OUTSIDE MIRROR (W/ MEMORY)
PNK/BLK WIRE
REAR DEFOGGER SWITCH INPUT
RELAY ENERGIZED
W/O MEMORY
WHT WIRE
WHT/ORG WIRE
Go to component -> Defoggers circuit, w/ auto defogger (2 of 2) -> REAR DEFOGGER SWITCH INPUT
Wiring diagram rear defogger switch input (2 of 2)
A/C FUSE
BLK WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BRN/BLK WIRE
DEFOGGER
DRIVER POWER OUTSIDE MIRROR
DRIVER POWER OUTSIDE MIRROR (W/ MEMORY)
GRN WIRE
GRN/ORG WIRE
GROUND DISTRIBUTION SYSTEM
HOT AT ALL TIMES
ICU JUNCTION BLOCK
ICU-C
ICU-G
LIN
MODULE 11 FUSE
MODULE 4 FUSE
MODULE 8 FUSE
MSDI
NCA WIRE
ORG/BLK WIRE
OUTSIDE MIRROR CONTROL (IMS)
PASSENGER POWER OUTSIDE MIRROR
PASSENGER POWER OUTSIDE MIRROR (W/ MEMORY)
PNK/BLK WIRE
REAR DEFOGGER SWITCH INPUT
RELAY ENERGIZED
W/O MEMORY
WHT WIRE
WHT/ORG WIRE
Go to component -> Defoggers circuit, w/o auto defogger (2 of 2) -> REAR DEFOGGER SWITCH INPUT
