Kia Telluride I facelift (2022-2024) pab off warning lamp Wiring diagram
This page shows the only wiring diagram for the component.pab off warning lamp, which is found in the car Kia Telluride I facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pab off warning lamp (1 of 1)
A/BAG IND FUSE
AIR BAG 1 FUSE
AIR BAG 2 FUSE
B-CAN
B-CAN HIGH
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BRN WIRE
BRN/ORG WIRE
C-CAN HIGH
C-CAN LOW
CEN (-)
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
CRASH OUTPUT
CRASH UNLOCK
DRIVER SEAT BELT BUCKLE SWITCH
DRV SEAT BELT BUCKLE SW
GRN WIRE
GRN/BLK WIRE
GRY WIRE
GRY/ORG WIRE
HIGH PNK MEMORY PWR WIRE
HOT AT ALL TIMES
ICU JUNCTION BLOCK
ICU-C
ICU-D
ICU-E
ICU-F
ICU-G
INPUT CAPTURE
INPUT CAPTURE LOW
IPS CONTROL MODULE
MODULE 8 FUSE
MSDI
NCA WIRE
ON/START INPUT
ORG/ WIRE
ORG/BLK WIRE
P-CAN HIGH
P-CAN LOW
PAB OFF WARNING LAMP
PASS SEAT BELT SEAT BELT BUCKLE BUCKLE SW SW INPUT
PASSENGER FRONT IMPACT SENSOR
PASSENGER SEAT BELT BUCKLE SWITCH
PNK WIRE
RED WIRE
RED/BLU WIRE
RED/ORG WIRE
RELAY ENERGIZED
RH CTR
SEAT BELT BUCKLE SW INPUT
SEAT BELT BUCKLE SW SW INPUT INPUT
SRS CONTROL MODULE (UNDER CENTER CONSOLE)
WHT WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Supplemental restraints circuit (1 of 3) -> PAB OFF WARNING LAMP
