Kia Telluride I facelift (2022-2024) adas l-can high c-can high Wiring diagram
This page shows the only wiring diagram for the component.adas l-can high c-can high, which is found in the car Kia Telluride I facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram adas l-can high c-can high (1 of 1)
ADAS L-CAN HIGH C-CAN HIGH
ADAS L-CAN LOW
AMP
BLK WIRE
BRN WIRE
BRN/ORG WIRE
C-CAN
C-CAN LOW
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
DAC
DC/DC -
GRN/ORG WIRE
GRY/ORG WIRE
ICU JUNCTION BLOCK
ICU-G
INSTRUMENT CLUSTER
MCU
MICOM
MODULE 5 FUSE
MULTI-FUNCTION CAMERA UNIT
ON/START INPUT
REG
RELAY ENERGIZED
SIG GND 1
TRANSCEIVER/
W/ 4.2 INCH TFT LCD
WHT WIRE
YEL/ORG WIRE
Go to component -> Lane departure warning circuit -> ADAS L-CAN HIGH C-CAN HIGH
