Driver power seat circuit for Kia Telluride I (2019-2022)
Driver power seat circuit
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BWD
DN UP
DRIVER FRONT HEIGHT ADJUSTER MOTOR
DRIVER LUMBAR SUPPORT MOTOR (FWD/BWD)
DRIVER REAR HEIGHT ADJUSTER MOTOR
DRIVER RECLINING LIMIT SWITCH
DRIVER RECLINING MOTOR
DRIVER SEAT MANUAL SWITCH
DRIVER SLIDE MOTOR
FRONT HEIGHT ADJUSTER SWITCH
GRY WIRE
HOT AT ALL TIMES
ICU JUNCTION BLOCK
ICU-C
LUMBAR SUPPORT SWITCH (FWD/ BWD)
ORG/ WIRE
P/SEAT (DRV) FUSE
PNK WIRE
REAR HEIGHT ADJUSTER SWITCH
RECLINING LIMIT SWITCH
RECLINING SWITCH
RED WIRE
RED/BLK WIRE
SLIDE SWITCH
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/ORG WIRE
