Exterior lamps circuit, w/o led for Kia Telluride I (2019-2022)

ADC (DOWN) ADC (PULL DOWN) ADC (PULL UP) ADC (UP) ARISU CAN B+ (POWER) B+1 FUSE B-CAN HIGH B-CAN LOW BLK WIRE BLU WIRE BRN WIRE BRN/ORG WIRE COMPUTER DATA LINES SYSTEM E/R JUNCTION BLOCK GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GROUND GRY WIRE GRY/BLK WIRE HAZ SW HAZ SW IND HAZARD SWITCH HI MOUNT HOT AT ALL TIMES ICU JUNCTION BLOCK ICU JUNCTION BLOCK (LEFT SIDE OF DASH) ICU-A ICU-B ICU-C ICU-F ICU-G IND IPS CONTROL MODULE LEFT HEADLAMP LF MARKER LF TURN LR BRAKE LR MARKER LR TURN MODULE 8 FUSE MSDI (33 CH) NCA WIRE ORG/ WIRE PNK WIRE POSITION RED WIRE RF MARKER RF TURN RIGHT HEADLAMP RR BRAKE RR MARKER RR TURN SIDE MARKER STOP SW T/SIG SW TRAILER FUSE TURN W/ NAVIGATION W/O NAVIGATION WHT WIRE WHT/BLK WIRE WHT/ORG WIRE YEL WIRE YEL/ORG WIRE

BLK WIRE DRIVER POWER OUTSIDE MIRROR GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRY WIRE GRY/BLK WIRE HIGH MOUNTED STOP LAMP LEFT REAR COMBINATION LAMP LEFT REAR TURN SIGNAL LAMP LICENSE PLATE ASSEMBLY NCA WIRE ORG/ WIRE PASSENGER POWER OUTSIDE MIRROR RED WIRE RIGHT REAR COMBINATION LAMP RIGHT REAR TURN SIGNAL LAMP SIDE MARKER STOP TAIL TURN W/ SURROUND VIEW MONITOR W/O SURROUND VIEW MONITOR WHT WIRE WHT/BLK WIRE WHT/ORG WIRE YEL WIRE YEL/BLK WIRE YEL/ORG WIRE

ASIC B-CAN HIGH B-CAN LOW LIGHT SW SIG BACK-UP BACK-UP LAMPS CIRCUIT BLK WIRE BLU WIRE BRAKE SWITCH FUSE BRK SW BRK SW FUSE BRK TEST SW BRN/ORG WIRE C-CAN TRANSCEIVER CLUSTER FUSE COIL COMPUTER DATA LINES SYSTEM ESC MODULE GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GROUND GRY WIRE HEAD HIGH LOW HOT AT ALL TIMES HOT IN ON OR START IBU IBU 2 FUSE ICU JUNCTION BLOCK ICU-A ICU-G INSTRUMENT CLUSTER L TURN LED DRIVER LEFT TURN M-CAN TRANSCEIVER MARKER MEM PWR MEMORY PWR MF SW RETURN MICOM MODULE 4 FUSE MULTIFUNCTION SWITCH NCA WIRE OFF TAIL ON/START ORG/ WIRE R TURN RED WIRE RED/ORG WIRE RIGHT TURN STOP STOP LAMP SW STOP LAMP SWITCH STOP SIG TAIL ON TRAILER CONNECTOR W/ EPB W/O EPB WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE
