Kia Telluride I (2019-2022) hot w/ short term load latch relay energized Wiring diagram
This page shows the only wiring diagram for the component.hot w/ short term load latch relay energized, which is found in the car Kia Telluride I (2019-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot w/ short term load latch relay energized (1 of 1)
BCW IND
BCW ON/OFF SW
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
C-CAN HIGH
C-CAN LOW
COMPUTER DATA LINES SYSTEM
CRASH PAD SWITCH
DRIVER POWER OUTSIDE MIRROR
GRN WIRE
GROUND
GRY WIRE
HOT W/ SHORT TERM LOAD LATCH RELAY ENERGIZED
ICU JUNCTION BLOCK
ICU-C
ILLUM
L-CAN HIGH
L-CAN LOW
LEFT BLIND-SPOT COLLISION WARNING UNIT
LH BCW IND
MODULE 10 FUSE
NCA WIRE
ON/START IN
ORG/ WIRE
PASSENGER POWER OUTSIDE MIRROR
PNK WIRE
RED WIRE
RH BCW IND
RIGHT BLIND-SPOT COLLISION WARNING UNIT
STAUS IND
WHT WIRE
YEL WIRE
Go to component -> Blind spot monitoring circuit -> HOT W/ SHORT TERM LOAD LATCH RELAY ENERGIZED
