Kia Telluride I (2019-2022) driver mood lamp Wiring diagrams

B-CAN HIGH B-CAN LOW BLK WIRE BLU WIRE BLU/ORG WIRE BRN WIRE BRN/BLK WIRE COMPUTER DATA LINES SYSTEM DRIVER DOOR MOOD LAMP DRIVER MOOD LAMP GRN WIRE GROUND GRY WIRE GRY/BLK WIRE GRY/ORG WIRE HOT AT ALL TIMES ICU JUNCTION BLOCK ICU-G LEFT REAR DOOR MOOD LAMP LIN MEMORY PWR MODULE 8 FUSE MOOD LAMP CONTROL UNIT PASSENGER DOOR MOOD LAMP PASSENGER MOOD LAMP PNK WIRE RED WIRE RED/BLK WIRE RIGHT REAR DOOR MOOD LAMP WHT WIRE YEL WIRE YEL/BLK WIRE

AMP AMP FUSE B+3 INPUT B+4 INPUT BLU WIRE BRN/BLK WIRE BRN/ORG WIRE DATA LINK CONNECTOR DRIVER DOOR MOOD LAMP DRIVER IMS CONTROL MODULE DRIVER MOOD LAMP DRIVER SAFETY POWER WINDOW MODULE DRIVER SEAT MANUAL SWITCH DRIVER SMART KEY OUTSIDE HANDLE FROM B+3 FUSE (DIAGRAM 1 OF 8) FROM B+4 FUSE (DIAGRAM 1 OF 8) FRONT AIR VENTILATION SEAT CONTROL MODULE FRONT SEAT WARMER CONTROL MODULE FRONT SUNROOF CONTROLLER GRN WIRE GRN/BLK WIRE GRY WIRE HAZARD SWITCH ICU-B ICU-C ICU-G IPS CONTROL MODULE LEFT P/WINDOW FUSE LEFT REAR DOOR MOOD LAMP LEFT REAR SAFETY POWER WINDOW MODULE LEFT RR SEAT FUSE LOW DC-DC CONVERTER MODULE 11 FUSE MODULE 8 FUSE MOOD LAMP CONTROL UNIT NCA WIRE ORG/BLK WIRE P/SEAT (DRV) FUSE P/SEAT PASS FUSE PASSENGER DOOR MOOD LAMP PASSENGER MOOD LAMP PASSENGER SAFETY POWER WINDOW MODULE PASSENGER SEAT MANUAL SWITCH PASSENGER SMART KEY OUTSIDE HANDLE PNK WIRE RAIN SENSOR REAR OCCUPANT DETECTION SENSOR RED WIRE RED/BLK WIRE RIGHT P/WINDOW FUSE RIGHT REAR DOOR MOOD LAMP RIGHT REAR SAFETY POWER WINDOW MODULE S/HEATER FRT FUSE SUNROOF 1 FUSE W/O MEMORY W/ MEMORY W/ VENT SEAT W/O VENT SEAT WHT WIRE YEL WIRE YEL/BLK WIRE
