Kia Telluride I (2019-2022) auto light, photo sensor photo sensor Wiring diagram
This page shows the only wiring diagram for the component.auto light, photo sensor photo sensor, which is found in the car Kia Telluride I (2019-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram auto light, photo sensor photo sensor (1 of 1)
A/C FUSE
AUTO DEFOGGER ACTUATOR
AUTO DEFOGGER SENSOR
AUTO LIGHT, PHOTO SENSOR PHOTO SENSOR
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
BRN/BLK WIRE
BRN/ORG WIRE
CLUTCH
DRIVER TEMPERATURE ACTUATOR
E/R JUNCTION BLOCK
ELECTRONIC A/C COMPRESSOR (LEFT SIDE OF ENGINE)
ELECTRONIC CONTROL VALVE
GRN WIRE
GRY WIRE
GRY/BLK WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
HOT IN ON
HOT IN ON OR START
HOT W/ LONG TERM LOAD LATCH RELAY ON
ICU JUNCTION BLOCK
ICU-A
ICU-E
ICU-G
MODULE 6 FUSE
MODULE 9 FUSE
MULTI FUSE 2
NCA WIRE
ORG/ WIRE
PASSENGER TEMPERATURE ACTUATOR
PHOTO SENSOR
PNK WIRE
PTC HEATER
PTC HEATER 1 FUSE
PTC HEATER 1 RELAY
PTC HEATER 2 FUSE
PTC HEATER 2 RELAY
RED WIRE
SCL
SDA
SENS
TEMP
WHT WIRE
WHT/ORG WIRE
YEL WIRE
Go to component -> Automatic a/c circuit (2 of 4) -> AUTO LIGHT, PHOTO SENSOR PHOTO SENSOR
