Kia Telluride I (2019-2022) 510 ohm Wiring diagrams
This page contains all the electrical diagrams for the component. 510 ohm, in which he is found in the car Kia Telluride I (2019-2022). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram 510 ohm (1 of 2)
120 OHM
510 OHM
ABS IND.
AJAR SWITCH
AUTO HIGH BEAM IND
AUTO HOLD (GREEN) IND
AUTO HOLD (WHITE) IND
AUTO HOLD (YELLOW) IND
AUTO STOP (GREEN) IND
AUTO STOP (YELLOW) IND
BLK WIRE
C-CAN TRANSCEIVER
CHARGE IND
CHECK ENGINE IND
DRIVER DOOR LOCK ACTUATOR
EPB IND
ESC IND
ESC OFF IND
FCA IND
FROM PIN 39 (DIAGRAM 1 OF 4)
FROM PIN 40 (DIAGRAM 1 OF 4)
FRONT FOG IND
GREEN CONTROL
GRY WIRE
GRY/ORG WIRE
HIGH BEAM IND
IMMO IND
INSTRUMENT CLUSTER
LDWS (GREEN) IND
LDWS (WHITE) IND
LDWS (YELLOW) IND
LED LAMP FAIL IND
LEFT REAR DOOR LOCK ACTUATOR
LEFT TURN IND
LKA-L (GREEN) IND
LKA-L (WHITE) IND
LOW BEAM IND
LOW FUEL IND
M-CAN TRANSCEIVER
MASTER IND
MDPS IND
MICOM
OIL PRESSURE IND
PARKING BRAKE IND.
RIGHT TURN IND
SEAT BELT IND
TAIL ON IND
TPMS IND
TRIP SW(-)
UDA
WHITE CONTROL
WHT WIRE
WHT/BLK WIRE
Go to component -> Instrument cluster circuit, 3.5 inch mono lcd display (4 of 4) -> 510 OHM
Wiring diagram 510 ohm (2 of 2)
120 OHM
510 OHM
ABS IND.
AJAR SWITCH
AUTO HIGH BEAM IND
AUTO STOP (GREEN) IND
AUTO STOP (YELLOW) IND
BLK WIRE
C-CAN TRANSCEIVER
CHARGE IND
CHECK ENGINE IND
DRIVER DOOR LOCK ACTUATOR
EPB IND
ESC IND
ESC OFF IND
FCA IND
FROM PIN 39 (DIAGRAM 1 OF 4)
FROM PIN 40 (DIAGRAM 1 OF 4)
FRONT FOG IND
GREEN CONTROL
GRY WIRE
GRY/ORG WIRE
HIGH BEAM IND
IMMO IND
INSTRUMENT CLUSTER
LED LAMP FAIL IND
LEFT REAR DOOR LOCK ACTUATOR
LEFT TURN IND
LOW BEAM IND
LOW FUEL IND
M-CAN TRANSCEIVER
MASTER IND
MDPS IND
MICOM
OIL PRESSURE IND
PARKING BRAKE IND.
RIGHT TURN IND
SEAT BELT IND
TAIL ON IND
TPMS IND
TRIP SW(-)
UDA
WHT WIRE
WHT/BLK WIRE
Go to component -> Instrument cluster circuit, 7 inch tft display (4 of 4) -> 510 OHM
