Kia Stinger I facelift (2020-2024) rear defogger sw ind Wiring diagram

A/C 2 FUSE A/C CONTROL MODULE (LOWER CENTER OF HVAC CASE) A/C FUSE A/C RELAY A/C SWITCH AMBIENT TEMPERATURE SENSOR AUTO LIGHT, PHOTO SENSOR BLK WIRE BLOWER MOTOR BLU WIRE BRN WIRE BRN/ORG WIRE CLIMATE LOCAL LIN DEFOGGER SYSTEM DETENT E/R-A E/R-C E/R-D ECV (+) FET DRAIN FET GATE GRN WIRE GRY BLK/ WIRE GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES I/P-C I/P-F I/P-G ICU JUNCTION BLOCK ILL ISG B+ LEAK CURRENT AUTOCUT DEVICE LIN CLIMATE CTRL LOW DC-DC CONVERTER (AUDIO) MEM I/P MEM PWR O/P MEMORY 1 FUSE MEMORY PWR MODULE 5 FUSE MULTI MEDIA 1 FUSE MULTI MEDIA 3 FUSE ON INPUT ON/START INPUT ORG/ WIRE PCB BLOCK PHOTO SENSOR PNK WIRE REAR DEFOGGER SW REAR DEFOGGER SW IND RED WIRE RED/BLK WIRE RELAY ENERGIZED SENS GND SENS SPLY WHT WIRE WHT/BLK WIRE WHT/ORG WIRE YEL WIRE YEL/ORG WIRE
