Kia Stinger I facelift (2020-2024) mirror up Wiring diagram
This page shows the only wiring diagram for the component.mirror up, which is found in the car Kia Stinger I facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mirror up (1 of 1)
B-CAN HIGH
B-CAN LOW
BCW IND
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DDM FUSE
DEFOGGER
DEFOGGER, EXTERIOR LIGHTS SYSTEMS
DRIVER DOOR MODULE (IN DRIVER FRONT DOOR)
DRIVER POWER OUTSIDE MIRROR
FOLDING
FOLDING MOTOR
GRN WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
I/P-A
I/P-D
I/P-F
I/P-G
IBU 3 FUSE
ICU JUNCTION BLOCK
IPS CONTROL MODULE
LEAK CURRENT AUTO CUT DEVICE
LEFT RIGHT
LIMIT SWITCH
M HOR
M VER
MCU
MIRROR
MIRROR DOWN
MIRROR FOLD-
MIRROR LEFT
MIRROR RIGHT
MIRROR SELECT L
MIRROR SELECT R
MIRROR UNFOLD
MIRROR UP
MODULE 3 FUSE
MUF
NAVIGATION SYSTEM
NCA WIRE
ORG/BLK WIRE
OUTSIDE MIRROR
PNK WIRE
PUDDLE LAMP
RED WIRE
RELAY ENERGIZED
TURN LAMP
UP DOWN
VOLTAGE REGULATOR
WHT WIRE
YEL/BLK WIRE
YEL/ORG WIRE
Go to component -> Power mirror circuit (1 of 2) -> MIRROR UP
