Kia Stinger I facelift (2020-2024) lr wind sw sig up Wiring diagram

ANALOG SW (LOCAL) AST WINDOW AUTO DOWN AST WINDOW AUTO UP AST WINDOW DOWN AST WINDOW UP BLK WIRE BLU WIRE BLU/ORG WIRE BRN WIRE DOWN GRN WIRE GRN/BLK WIRE GRY WIRE HOT AT ALL TIMES I/P-A I/P-D ICU JUNCTION BLOCK ILL LEFT REAR DOOR MODULE (IN LEFT REAR DOOR) LEFT REAR POWER WINDOW MOTOR LR WIND SW SIG DOWN LR WIND SW SIG UP LSD ORG/ WIRE ORG/BLK WIRE P/WINDOW RH FUSE PASSENGER DOOR MODULE (IN PASSENGER FRONT DOOR) PNK WIRE REAR WIND SW LOCK SIG RED WIRE RED/BLK WIRE RIGHT REAR DOOR MODULE (IN RIGHT REAR DOOR) RIGHT REAR POWER WINDOW MOTOR RR WIND SW SIG DOWN RR WIND SW SIG UP W LOCK YEL WIRE YEL/BLK WIRE YEL/ORG WIRE
