Kia Stinger I facelift (2020-2024) ind sw sens Wiring diagram
This page shows the only wiring diagram for the component.ind sw sens, which is found in the car Kia Stinger I facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ind sw sens (1 of 1)
BACKUP LAMPS SIG
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER POWER OUTSIDE MIRROR
ECM GLASS (-)
ECM MIRROR
ELECTROCHROMIC MIRROR
GROUND
GRY/BLK WIRE
I/P-G
ICU JUNCTION BLOCK
IND SW SENS
MODULE 5 FUSE
NCA WIRE
ON/START INPUT
PASSENGER POWER OUTSIDE MIRROR
PCB
PNK ECM GLASS (+) WIRE
PNK WIRE
PNK/BLK WIRE
PNK/ORG WIRE
RED WIRE
RELAY ENERGIZED
YEL WIRE
Go to component -> Electrochromic mirror circuit -> IND SW SENS
