Car Wiring Diagrams for Backup lamps circuit for Kia Stinger I (2017-2021)

B+1 FUSE BACKUP LAMP BLK WIRE BLU WIRE BRN/ORG WIRE COMPUTER DATA LINES SYSTEM CTRL E/R JUNCTION BLOCK E/R-F ELECTROCHROMIC MIRROR H-MATIC H-MATIC SHIFT BY WIRE HOT AT ALL TIMES HOT W/ I/P-A I/P-B I/P-G INHIBITOR SW INHIBITOR SW SIG INHIBITOR SW SIG GND PARKING SW GND IPS CONTROL MODULE LEFT REAR COMBINATION LAMP (IN) MULTI FUSE 2 ON/START INPUT ORG/ WIRE P RANGE SW P-CAN P-CAN HIGH P-CAN LOW PARKING SW PWR PCB BLOCK RED WIRE RIGHT REAR COMBINATION LAMP (IN) SIG (1) SIG 2 SIG S TCM TCU 2 FUSE TRANSMISSION PARK POSITION SENSOR/ SWITCH TRANSMISSION RANGE SWITCH WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE
