Kia Stinger I (2017-2021) stop lamp low sw Wiring diagram
This page shows the only wiring diagram for the component.stop lamp low sw, which is found in the car Kia Stinger I (2017-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram stop lamp low sw (1 of 1)
2.0L TURBO
3.3L TURBO
ABS IND.
AEB IND
BLK WIRE
BLU WIRE
BRAKE FLUID LEVEL SENS
BRAKE FLUID LEVEL SENSOR
BRAKE LAMP
BRAKE LIGHT
BRAKE TEST
BRN WIRE
BRN/ORG WIRE
C-CAN
C-CAN HIGH
C-CAN TRANSCEIVER
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
E/R JUNCTION BLOCK
ELECTRONIC ATM SHIFT LEVER
ELECTRONIC VACUUM PUMP
ESC IND
ESC OFF IND
FOOT PARKING BRAKE SWITCH
GRN WIRE
GRN/BLK WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
I/P-C
I/P-F
I/P-G
IBU
ICU JUNCTION BLOCK
INSTRUMENT CLUSTER
IPS CONTROL MODULE
MICOM
MSDI
ORG/ WIRE
PARKING BRAKE IND.
PARKING BRAKE SWITCH
PNK WIRE
RELAY ENERGIZED
SIG (RR)
SIG 3 GND
SPEED INPUT
STOP LAMP
STOP LAMP LOW SW
VACUUM PUMP FUSE
VACUUM PUMP RELAY
VEHICLE
WHEEL SENS
WHT/BLK WIRE
Go to component -> Anti-lock brakes circuit, w/o epb (3 of 3) -> STOP LAMP LOW SW
