Kia Stinger I (2017-2021) rvm rvm sw sw ind i/p Wiring diagram
This page shows the only wiring diagram for the component.rvm rvm sw sw ind i/p, which is found in the car Kia Stinger I (2017-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rvm rvm sw sw ind i/p (1 of 1)
AUDIO
B-CAN HIGH
B-CAN LOW
BLK WIRE
BRN WIRE
C-CAN HIGH
C-CAN LOW
CAMERA P GND
CAMERA PWR
CAMERA SHIELD
CAMERA V GND
CAMERA V IN
COMPUTER DATA LINES SYSTEM
CONSOLE SWITCH (FRONT)
GRN WIRE
GRY WIRE
I/P-F
I/P-G
ICU JUNCTION BLOCK
ILL
IPS CONTROL MODULE
MODULE 5 FUSE
NCA WIRE
ON/START I/P
ORG/ WIRE
PWR
REAR VIEW CAMERA (CENTER OF TAILGATE)
RED WIRE
RELAY ENERGIZED
RVM RVM SW SW IND I/P
RVM SWITCH
VIDEO GND
VIDEO OUT
WHT WIRE
WHT/BLK WIRE
YEL/ORG WIRE
Go to component -> Rear view camera circuit -> RVM RVM SW SW IND I/P
