Kia Stinger I (2017-2021) backup sw out Wiring diagrams
This page contains all the electrical diagrams for the component. backup sw out, in which he is found in the car Kia Stinger I (2017-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
backup sw out wiring diagram (1 of 2)
AUTO LIGHT SENS GND
AUTO LIGHT SENS SIG
AUTO LIGHT SENS SPLY
AUTO LIGHT SENSOR
B-CAN HIGH
B-CAN LOW
BACKUP SW OUT
BCM
BLK WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
DIMMER
GRY WIRE
HEADLAMP
HEADLAMP HIGH SW IN
HEADLAMP LOW
HIGH SW OUT
HOT W/
I/P-E
I/P-F
IBU (LOWER RIGHT SIDE OF HVAC CASE)
IBU 4 FUSE
ICU JUNCTION BLOCK
LIGHT
LIGHT SW SIG
MULTI- FUNCTION SWITCH
OFF
ON/START INPUT
PASSING
SW OUT
TAIL HEADLAMP
WHT WIRE
WIPER, LIGHT GND
Go to component -> Autolamps circuit (1 of 3) -> BACKUP SW OUT
backup sw out wiring diagram (2 of 2)
B-CAN HIGH
B-CAN LOW
BACKUP SW OUT
BCM
BLK WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
DIMMER
GRY WIRE
HEADLAMP
HEADLAMP HIGH SW IN
HEADLAMP LOW
HIGH SW OUT
HOT W/
I/P-E
I/P-F
IBU (LOWER RIGHT SIDE OF HVAC CASE)
IBU 4 FUSE
ICU JUNCTION BLOCK
LIGHT
LIGHT SW SIG
MULTI- FUNCTION SWITCH
OFF
ON/START INPUT
PASSING
SW OUT
TAIL
WHT WIRE
WIPER, LIGHT GND
Go to component -> Headlamps circuit (1 of 3) -> BACKUP SW OUT
